SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads1 that record video from 64 HD cameras.
SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.2 Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.
Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.
RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.
ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.
1 M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
Features | |
---|---|
Mean time between failures (MTBF) | 1000000 h |
Workload rate limit | 180 TB/year |
Start/stop cycles | 600000 |
Maximum number of cameras supported | 64 |
RV sensor(s) | Yes |
24/7 operation | Yes |
Rotational Vibration (RV) sensors | Yes |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^14 bits read |
HDD sustained transfer rate | 180 MiB/s |
HDD interface transfer rate | 6 Gbit/s |
Storage drive buffer size | 256 MB |
Component for | PC |
Type | HDD |
Interface | Serial ATA III |
HDD capacity | 6 TB |
HDD size | 3.5" |
Power | |
---|---|
Start-up current | 1.8 A |
Operating voltage | 5 / 12 V |
Power consumption (idle) | 3.4 W |
Power consumption (off) | 0.25 W |
Power consumption (typical) | 5.3 W |
Operational conditions | |
---|---|
Operating temperature (T-T) | 0 - 65 °C |
General | |
---|---|
Product Family | SkyHawk |
Weight & dimensions | |
---|---|
Weight | 630 g |
Height | 26.1 mm |
Depth | 147 mm |
Width | 101.6 mm |
