| Display |
|---|
| HDCP |
Yes |
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Dynamic contrast ratio marketing name |
SmartContrast |
| Display number of colours |
16.78 million colours |
| Native aspect ratio |
16:9 |
| Pixel density |
93 ppi |
| DDC/CI |
Yes |
| Colour gamut |
72% |
| Maximum refresh rate |
60 Hz |
| Display surface |
Gloss |
| HD type |
Full HD |
| Display technology |
LCD |
| Contrast ratio (dynamic) |
50000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.275 x 0.275 mm |
| Horizontal scan range |
30 - 85 kHz |
| Vertical scan range |
48 - 75 Hz |
| Aspect ratio |
16:9 |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Digital horizontal frequency |
30 - 85 kHz |
| Digital vertical frequency |
48 - 75 Hz |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Supported video modes |
1080p |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
5 ms |
| Display diagonal |
60.5 cm (23.8") |
| Contrast ratio (typical) |
1000:1 |
| Surface hardness |
7H |
| NTSC coverage (typical) |
72% |
| Touchscreen type |
Tabletop |
| Touchscreen |
No |
| Number of simultaneous touchpoints |
10 |
| Panel type |
IPS |
| RGB colour space |
sRGB |
| Display diagonal (metric) |
60.5 cm |
| Display sRGB |
Yes |
| Touch technology |
Multi-touch |
| Touchscreen technology |
Projected capacitive system |
| LED backlight |
Yes |
| Display brightness |
250 cd/m² |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Mean time between failures (MTBF) |
70000 h |
| Built-in microphone |
No |
| Built-in camera |
No |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Component video sync |
Separate sync, Sync-on-green (SOG) |
| EasyRead mode |
Yes |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Turkish, Ukrainian |
| Plug and Play |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Built-in microphone |
No |
| Built-in camera |
No |
| Design |
|---|
| Heavy metals free |
Hg (mercury), Pb (lead) |
| Feet colour |
Black |
| Certification |
CB, CE Mark, FCC Class B, SEMKO, EPA, UKRAINIAN, ICES-003, TUV/GS, TUV Ergo, CU-EAC, EAEU |
| Product colour |
Black |
| Front bezel colour |
Black |
| International Protection (IP) code |
IP65 |
| Mean time between failures (MTBF) |
70000 h |
| Exterior finish type |
Textured |
| Camera |
|---|
| Built-in camera |
No |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB Type-A downstream ports quantity |
2 |
| Headphone out |
Yes |
| DVI port |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| DVI-D ports quantity |
1 |
| HDMI ports quantity |
1.4 |
| DisplayPorts quantity |
1.2 |
| HDCP |
Yes |
| Audio input |
1 |
| Headphone outputs |
1 |
| PC Audio in |
Yes |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| USB Touch port |
Yes |
| Technical details |
|---|
| Height (without stand) |
33.8 cm |
| Depth (without stand) |
5 cm |
| Width (without stand) |
55.4 cm |
| Mobile operating systems supported |
Android |
| Feet colour |
Black |
| Cable lock slot |
Yes |
| Mean time between failures (MTBF) |
70000 h |
| HDMI |
Yes |
| Display viewable area (HxV) |
527 x 296.5 mm |
| Built-in microphone |
No |
| Product colour |
Black |
| Recommended resolution |
1920 x 1080 @ 60 Hz |
| Picture enhancement |
SmartImage |
| Recyclable packaging material |
100% |
| Regulatory Approvals |
CB; CE Mark; FCC Class B; SEMKO; UKRAINIAN; ICES-003; TUV/GS; TUV Ergo; CU-EAC; EAEU RoHS; cETLus |
| Front bezel colour |
Black |
| Sustainability certificates |
RoHS, ENERGY STAR |
| Doesn't contain |
PVC/BFR, Mercury |
| Power supply type |
AC |
| Touch method |
Stylus, Finger, Glove |
| Surface hardness |
7H |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Touchscreen type |
Tabletop |
| Touchscreen |
No |
| Number of simultaneous touchpoints |
10 |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Bundled software |
SmartControl |
| Ergonomics |
|---|
| Wall mountable |
Yes |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| LED indicators |
Operation, Stand-by |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Turkish, Ukrainian |
| Plug and Play |
Yes |
| Height adjustment |
No |
| Cable lock slot type |
Kensington |
| Power |
|---|
| Power supply type |
AC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
15.68 W |
| Power consumption (off) |
0.3 W |
| Power consumption (PowerSave) |
11.5 W |
| Energy efficiency scale |
A+++ to D |
| Energy efficiency class (SDR) |
E |
| Energy consumption (SDR) per 1000 hours |
18 kWh |
| Operational conditions |
|---|
| Non-operating altitude |
3658 - 12192 m |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating altitude |
0 - 3658 m |
| Packaging content |
|---|
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
HDMI, USB Type-A to USB Type-B, AC |
| Bundled software |
SmartControl |
| Stylus included |
Yes |
| Weight & dimensions |
|---|
| Height (without stand) |
33.8 cm |
| Depth (without stand) |
5 cm |
| Width (without stand) |
55.4 cm |
| Weight (without stand) |
4.86 kg |
| Package width |
620 mm |
| Package depth |
168 mm |
| Package height |
433 mm |
| Package weight |
7.77 kg |
| Packaging data |
|---|
| Package width |
620 mm |
| Package depth |
168 mm |
| Package height |
433 mm |
| Package weight |
7.77 kg |
| Package type |
Box |
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
HDMI, USB Type-A to USB Type-B, AC |
| Bundled software |
SmartControl |
| Stylus included |
Yes |
| Sustainability |
|---|
| Sustainability certificates |
RoHS, ENERGY STAR |
| Doesn't contain |
PVC/BFR, Mercury |
| Indication |
|---|
| LED indicators |
Operation, Stand-by |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Other features |
|---|
| Height (without stand) |
33.8 cm |
| Depth (without stand) |
5 cm |
| Width (without stand) |
55.4 cm |
| HDMI |
Yes |
| Surface hardness |
7H |
| Energy efficiency scale |
A+++ to D |
| Power supply type |
AC |
| Mobile operating systems supported |
Android |
| Mean time between failures (MTBF) |
70000 h |
| Manual |
Yes |
| Display viewable area (HxV) |
527 x 296.5 mm |
| Connection to PC |
Yes |
| Recommended resolution |
1920 x 1080 @ 60 Hz |
| Picture enhancement |
SmartImage |
| Recyclable packaging material |
100% |
| Regulatory Approvals |
CB; CE Mark; FCC Class B; SEMKO; UKRAINIAN; ICES-003; TUV/GS; TUV Ergo; CU-EAC; EAEU RoHS; cETLus |
| Touch method |
Stylus, Finger, Glove |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Touchscreen type |
Tabletop |
| Touchscreen |
No |
| Number of simultaneous touchpoints |
10 |
| Exterior finish type |
Textured |
| Energy efficiency class (old) |
A |
| Package type |
Box |
| Front bezel colour |
Black |
| Certificates |
|---|
| Certification |
CB, CE Mark, FCC Class B, SEMKO, EPA, UKRAINIAN, ICES-003, TUV/GS, TUV Ergo, CU-EAC, EAEU |
