Cooling | |
---|---|
Fan diameter | 13.5 cm |
Design | |
80 PLUS certification | 80 PLUS Titanium |
Product colour | Black |
Fan diameter | 13.5 cm |
Power | |
Total power | 1600 W |
AC input voltage | 100 - 240 V |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 1600 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 22 A |
Max output current (+12V) | 133.3 A |
Max output current (+5V) | 22 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
Efficiency | 94% |
Ports & interfaces | |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 8 |
Peripheral (Molex) power connectors (4-pin) | 8 |
EPS power connector (8-pin) | No |
PCI Express power connectors (6+2 pin) | 9 |
Cabling type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
PCI Express power connectors (16-pin) | 2 |
Performance | |
Power supply unit (PSU) form factor | ATX |
80 PLUS certification | 80 PLUS Titanium |
Purpose | PC |
Bearing technology | DBB |
Weight & dimensions | |
Width | 190 mm |
Depth | 150 mm |
Height | 86 mm |
Certificates | |
80 PLUS certification | 80 PLUS Titanium |
