ThinkVision M14d has 14" screen, 16:10 aspect ratio, 104 PPI, 2240 x 1400 resolution screen with 100% sRGB colour gamut which ensure rich, clear imagery and true-to-life colours. M14d comes with two Type-C ports for quick upstream and downstream connectivity, allowing you to connect your notebook effortlessly. In addition, the Type-C ports have the ‘power pass-through’ feature that allows you to power the monitor and charges your notebook simultaneously. The mobile monitor also has the Natural Low Blue Light technology which reduces the harmful blue light to make viewing a comfortable and stress-free experience without colour distortion.
The all-out visual performer
The ThinkVision M14d Mobile Monitor has a 2.2K, 104 PPI, 2240 x 1400 resolution screen with IPS panel that offers excellent, sharp performance, and superb visibility from wide viewing angles. Its 16:10 aspect ratio and its ‘mirror and extend’ feature means that it is perfectly aligned with the viewing format of your 16:10 notebook. This mobile monitor comes with a 100% sRGB color gamut and 105% sRGB color space which is consistent with notebooks and displays rich, true-to-life colors. No wonder it adapts easily to your mobile lifestyle and gives your personal productivity a big boost.
Power pass-through for extra convenience
The ThinkVision M14d Mobile Monitor will delight you with its connectivity and convenience. This monitor comes with 2 x USB Type-C ports with up to 65W power pass-through. This unique feature means you can power your ThinkVision M14d Mobile Monitor and charge your notebook simultaneously while keeping your desk clutter-free. Now, you don’t have to worry about charging multiple devices. Just charge your notebook and connect your mobile monitor for uninterrupted performance.
Portable & comfortable
Weighing in at less than 600 grams, this slim, lightweight, ultra-portable monitor’s 14-inch screen is just 4.6 mm thick, making it very easy to carry. The ThinkVision M14d Mobile Monitor also comes with Natural Low Blue Light technology that protects your eyes from harmful blue light enables you to have a strain-free viewing experience without color distortion. Even when you are viewing it for long hours. Its Mount feature helps you adjust the monitor for enhanced ergonomics and comfort. In addition, the ThinkVision M14d comes with a height adjustment support feature that further enhances the user experience.
Display | |
---|---|
sRGB coverage (typical) | 100% |
RGB colour space | sRGB |
Colour depth | 8 bit |
Viewable size, vertical | 18.9 cm |
Viewable size, horizontal | 30.1 cm |
Pixel density | 104 ppi |
Pixel pitch | 0.135 x 0.135 mm |
Response time (fast) | 6 ms |
Display number of colours | 16.7 million colours |
Viewing angle, vertical | 178° |
Viewing angle, horizontal | 178° |
Maximum refresh rate | 60 Hz |
Contrast ratio (dynamic) | 3000000:1 |
Contrast ratio (typical) | 1500:1 |
Screen shape | Flat |
Anti-glare screen | Yes |
Response time | 8 ms |
Display brightness (typical) | 300 cd/m² |
Display brightness (peak) | 375 cd/m² |
Backlight type | W-LED |
Panel type | IPS |
HD type | 2.2K |
Touchscreen | No |
Display technology | LED |
Native aspect ratio | 16:10 |
Display resolution | 2240 x 1400 pixels |
Display diagonal | 35.6 cm (14") |
Performance | |
---|---|
Low Blue Light technology | Yes |
Multimedia | |
---|---|
Built-in camera | No |
Built-in speaker(s) | No |
Design | |
---|---|
Certification | Energy Star Certified, EPEAT Silver, RoHSEyesafe Display, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Low Blue Light, TÜV Rheinland Flicker Free |
Product colour | Black |
Ports & interfaces | |
---|---|
HDMI | No |
USB Type-C DisplayPort Alternate Mode | Yes |
USB Type-C downstream ports quantity | 1 |
Number of USB Type-C upstream ports quantity | 1 |
Number of upstream ports | 1 |
USB upstream port type | USB Type-C |
Built-in USB hub | Yes |
Ergonomics | |
---|---|
Tilt adjustment | Yes |
On Screen Display (OSD) | Yes |
Tilt angle range | -5 - 95° |
Height adjustment | 1.1 cm |
Height adjustment | Yes |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Panel mounting interface | 100 x 100 mm |
VESA mounting | Yes |
Power | |
---|---|
Power supply type | External |
Power consumption (off) | 0.5 W |
Power consumption (max) | 7.5 W |
Power consumption (typical) | 6 W |
Packaging content | |
---|---|
Quick start guide | Yes |
Cables included | USB Type-C |
Stand included | Yes |
Weight & dimensions | |
---|---|
Bezel width (bottom) | 1.89 cm |
Bezel width (top) | 4.9 mm |
Bezel width (side) | 4.9 mm |
Weight (without stand) | 400 g |
Height (without stand) | 215.3 mm |
Depth (without stand) | 4.6 mm |
Width (without stand) | 314.4 mm |
Weight (with stand) | 600 g |
Depth (with stand) | 106.4 mm |
Width (with stand) | 314.4 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.8 kg |
Package height | 277 mm |
Package depth | 76 mm |
Package width | 384 mm |
General | |
---|---|
Product Family | ThinkVision |
