Intel Core i5-1235U, 10C (2P + 8E)/12T, P-core 1.3/4.4GHz, E-core 0.9/3.3GHz, 12MB, 16GB LPDDR5-5200, 512GB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal2, 14" 2.8K (2880x1800) OLED 400nits Anti-glare / AR (anti-reflection) / AS (anti-smudge), Intel Iris Xe Graphics, Intel AX211 Wi-Fi 6E 2x2 + BT5.1, Discrete IR & FHD 1080p MIPI with Privacy Shutter, Computer Vision, Windows 11 Pro 64

Redesigned with collaboration in mind
The 10th generation of our premium ThinkPad X1 Carbon laptop is built on the Intel® Evo platform and powered by up to 12th Gen Intel® Core™ vPro® processors. It still has the legendary ThinkPad keyboard, only now we’ve redesigned the keys to create better airflow, in addition to rear exhaust ventilation. We’ve also transformed the camera into a Communications Bar to improve videoconferencing.

Serious productivity enhancer
Powered by 12th Gen Intel® Core™ vPro® processors—with up to 14 cores—our legendary ThinkPad X1 Carbon Gen 10 laptop takes multitasking to the next level. These CPUs have a revolutionary design that intelligently allocate workloads to the right thread, on the right core, at the right time—which allows for better video collaboration and productivity based on how you’re actually using your device.

Communication just got a lot nicer
Say hello to the Communications Bar, a gorgeous new design that houses the higher resolution FHD camera with optional infrared (IR) and Computer Vision features—all with a webcam privacy shutter. It also shows off the 4 x 360-degree mics with integrated AI-based noise-cancellation and Dolby Voice®. The Communications Bar not only looks great—it inspires seamless collaboration and vibrant video calls.

Keeps cool under pressure
The underside of the keys on our legendary ThinkPad keyboard have been redesigned for air intake to create better airflow. Combined with the dual fan and rear venting, the ThinkPad X1 Carbon Gen 10 laptop delivers improved thermals—so go ahead and put in long hours working and playing as this X1 will stay as cool as you are.

Missing laptop? No problem.
If you misplace your laptop, or worse, if someone takes it, locating your device has never been so easy. Now Tile® ready, the ThinkPad X1 Carbon Gen 10 works with your smartphone to find your device—even when your X1 is powered off. Simply subscribe to the Tile® service*, and then download, set up, and activate.

Security as unique as your DNA
Biometrics provide extra security on the ThinkPad X1 Carbon Gen 10 laptop—from the power button integrated with the fingerprint reader that lets you log in and boot up instantaneously, to the facial recognition software that works with the IR camera. Plus, Computer Vision based presence detection automatically locks your device when you move away, and with the optional PrivacyGuard display, no wandering eyes see what’s on your screen.

Displays that dazzle
Whether your position requires richly detailed graphical displays or extra security to keep spying eyes away, the ThinkPad X1 Carbon Gen 10 laptop has an option for you. Ranging from 4K WQUXGA touch to 2.8K OLED, to WUXGA and even ePrivacy, all 14" panels feature a 16:10 aspect ratio with narrow bezels. Most displays also include low-power usage and Eyesafe® certification to reduce blue-light emissions.

Count on ThinkPad every time
We use the US Department of Defense's MIL-STD 810H standards to create a balance of reliability and durability for our ThinkPad laptops. We test against 12 standards and more than 200 quality checks to ensure they run in extreme conditions. These tests cover harsh variables like Arctic wilderness and desert dust storms, including temperature, pressure, humidity, vibration, and more.

Design
Housing material	Aluminium, Carbon fibre
Form factor	Clamshell
Colour name	Black, Weave
Product colour	Black
Product type	Laptop

Display
Display brightness	400 cd/m²
Anti-glare screen	Yes
LED backlight	Yes
Native aspect ratio	16:10
Panel type	OLED
HD type	2.8K
Touchscreen	No
Display resolution	2880 x 1800 pixels
Display diagonal	35.6 cm (14")

Processor
Configurable TDP-down	12 W
Motherboard chipset	Intel SoC
Processor cache	12 MB
Processor cores	10
Processor boost frequency	4.4 GHz
Processor frequency	1.3 GHz
Processor model	i5-1235U
Processor generation	12th gen Intel® Core™ i5
Processor family	Intel® Core™ i5
Processor manufacturer	Intel

Memory
Memory channels	Octa-channel
Maximum internal memory	16 GB
Memory clock speed	5200 MHz
Memory form factor	On-board
Internal memory type	LPDDR5-SDRAM
Internal memory	16 GB

Storage
Card reader integrated	No
Optical drive type	No
SSD form factor	M.2
SSD interface	PCI Express
SSD capacity	512 GB
Number of SSDs installed	1
Total SSDs capacity	512 GB
Storage media	SSD
Total storage capacity	512 GB

Graphics
On-board graphics card model	Intel Iris Xe Graphics
On-board GPU manufacturer	Intel
Discrete graphics card model	Not available
Discrete graphics card	No
On-board graphics card	Yes

Audio
Number of microphones	4
Built-in microphone	Yes
Number of built-in speakers	4
Audio system	Dolby Atmos
Audio chip	Realtek ALC3306

Camera
Privacy type	Privacy shutter
Privacy camera	Yes
Infrared (IR) camera	Yes
Front camera	Yes

Network
WWAN	Installed
Near Field Communication (NFC)	No
Bluetooth version	5.2
Bluetooth	Yes
Ethernet LAN	No
WLAN controller model	Intel Wi-Fi 6E AX211
WLAN controller manufacturer	Intel
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Mobile network connection	No

Ports & interfaces
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB Power Delivery	Yes
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
Headphone outputs	1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
HDMI ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2

Keyboard
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	English
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav

Software
Bundled software	Intel Connectivity Performance Suite
Operating system language	English
Windows 11 free upgrade	No
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Processor special features
Intel Flex Memory Access	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Execute Disable Bit	Yes
CPU configuration (max)	1
Embedded options available	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes

Battery
Battery capacity	57 Wh
Battery technology	Lithium Polymer (LiPo)

Power
AC adapter power	65 W

Security
Password protection type	Power on, Supervisor, SSD
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Fingerprint reader	Yes
Smart card reader	No
Cable lock slot type	Kensington
Cable lock slot	Yes

Operational conditions
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	8 - 95%
Storage temperature (T-T)	5 - 43 °C
Operating temperature (T-T)	5 - 35 °C

Certificates
Compliance certificates	RoHS

Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, TCO

Weight & dimensions
Height	15.4 mm
Depth	222.5 mm
Width	315.6 mm
Weight	1.12 kg

General
Product Family	ThinkPad

Logistics data
Harmonized System (HS) code	84713000
