WINDFORCE 3X COOLING SYSTEM
The WINDFORCE 3X cooling system features 3x 82mm unique blade fans, alternate spinning fan, 6 composite copper heat pipes, heat-pipe direct touch and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
ALTERNATE SPINNING
The middle fan spins in reverse to optimize airflow for heat dissipation , enabling more efficient performance at lower temperatures.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
COMPOSITE HEAT-PIPES
The composite heat-pipes combines thermal conductivity and phase transition to efficiently manage the heat transfer between two solid interfaces which increases cooling capacity.
GAME IN STYLE
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose the right scheme for your gaming rig with the AORUS engine.
EXTREME DURABILITY AND OVERCLOCKING
The graphics card uses the 8+2 power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
POWER INDICATORS
The smart power LED indicator alerts the player when any PCI-E power supply is abnormal.
NVIDIA NVLINKTM SUPPORT
Support for NVIDIA NVLinkTM (NVIDIA SLI) technology, which combines 2 identical GPUs with an GeForce RTX NVLink Bridge to deliver the ultimate experience in 4K gaming or VR gaming. You can also adjust the light effect on the bridge with the AORUS Engine.
AORUS ENGINE
The cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your games requirements.
ONE-CLICK SUPER OVERCLOCKING
Simply click on the AORUS engine and you can easily adjust the card to meet different requirements without any overclocking knowledge.
Processor | |
---|---|
FireStream | No |
Graphics processor family | NVIDIA |
Processor frequency | 1650 MHz |
Parallel processing technology support | NVLink |
Maximum displays per videocard | 4 |
Maximum digital resolution | 7680 x 4320 pixels |
CUDA cores | 4352 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 2080 Ti |
Processor frequency (OC mode) | 1665 MHz |
Memory | |
Discrete graphics adapter memory | 11 GB |
Memory clock speed | 14000 MHz |
Memory bandwidth (max) | 616 GB/s |
Memory bus | 352 bit |
Graphics adapter memory type | GDDR6 |
Ports & interfaces | |
HDMI version | 2.0b |
HDMI ports quantity | 1 |
DisplayPort version | 1.4 |
DisplayPorts quantity | 3 |
Interface type | PCI Express x16 3.0 |
USB Type-C ports quantity | 1 |
Video | |
DirectX version | 12.0 |
Shader model version | 5.0 |
OpenGL version | 4.5 |
HDMI version | 2.0b |
HDCP | Yes |
Full HD | Yes |
Dual Link DVI | No |
CUDA cores | 4352 |
NVIDIA 3D Vision | Yes |
PhysX | Yes |
Performance | |
NVIDIA G-SYNC | Yes |
Virtual Reality (VR) ready | Yes |
DirectX version | 12.0 |
Shader model version | 5.0 |
OpenGL version | 4.5 |
HDCP | Yes |
Full HD | Yes |
Dual Link DVI | No |
NVIDIA 3D Vision | Yes |
TV tuner integrated | No |
PhysX | Yes |
Design | |
Number of fans | 3 fan(s) |
Cooling type | Active |
Form factor | Full-Height/Full-Length (FH/FL) |
Product colour | Black |
Number of slots | 2 |
Bracket height | Full-Height (FH) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Software | |
Windows operating systems supported | Yes |
Power | |
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 650 W |
Weight & dimensions | |
Number of slots | 2 |
Width | 286.5 mm |
Height | 114.5 mm |
Depth | 50.2 mm |
Technical details | |
Cooling type | Active |
Form factor | Full-Height/Full-Length (FH/FL) |
Product colour | Black |
TV tuner integrated | No |
System requirements | |
Windows operating systems supported | Yes |
Minimum system power supply | 650 W |
