Cooling | |
---|---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Performance | |
On/off switch | Yes |
Power supply unit (PSU) form factor | ATX |
80 PLUS certification | 80 PLUS Gold |
Purpose | PC/Server |
ATX version | 3.0 |
Mean time between failures (MTBF) | 100000 h |
Certification | ErP 2014 Lot 3 |
Bearing technology | HDB |
Design | |
80 PLUS certification | 80 PLUS Gold |
Certification | ErP 2014 Lot 3 |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Power | |
Total power | 750 W |
Power Good signal delay range | 100 - 150 ms |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Input current | 5 - 10 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 100 W |
Combined power (+12V) | 750 W |
Combined power (+5V) | 100 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 62.5 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Hold time | 16 ms |
Efficiency | 90% |
Ports & interfaces | |
Motherboard power cable length | 61 cm |
SATA power cable length | 500,620,740,860 mm |
Peripheral (Molex) power cable length | 860,740,620,500 mm |
PCI Express power cable length | 67 cm |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 12 |
Peripheral (Molex) power connectors (4-pin) | 4 |
EPS power connector (8-pin) | Yes |
PCI Express power connectors (6+2 pin) | 4 |
Cabling type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
EPS cable length | 65 cm |
PCI Express power connectors (12+4 pin) | 1 |
PCI Express power connectors (12+4 pin) cable length | 650 mm |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions | |
Width | 150 mm |
Depth | 160 mm |
Height | 86 mm |
Weight | 2.62 kg |
Packaging data | |
Package depth | 310 mm |
Package width | 194 mm |
Package height | 120 mm |
Package type | Box |
Package weight | 2.9 kg |
Technical details | |
Sustainability compliance | Yes |
Compliance certificates | BIS, BSMI, CCC, EAC, Federal Communications Commission (FCC), RCM, cTUVus, UKCA |
Certificates | |
80 PLUS certification | 80 PLUS Gold |
Certification | ErP 2014 Lot 3 |
Logistics data | |
Master (outer) cases per pallet | 16 pc(s) |
Master (outer) case width | 325 mm |
Master (outer) case length | 620 mm |
Master (outer) case height | 220 mm |
Products per master (outer) case | 5 pc(s) |
Other features | |
EPS cable length | 65 cm |
