Passive Cooling. Silent Gaming.
Introducing the Palit GeForce RTX™ 3050 KalmX, where silence meets performance in perfect harmony. The KalmX series, renowned for its ingenious fan-less design, redefines your gaming experience. With its passive cooling system, this graphics card operates silently, making it ideal for both gaming and multimedia applications.
KalmX is all about silence. With passive cooling, there are no distracting fan noises – just pure, uninterrupted gaming bliss. Focus on what matters: elevate your display, silence the rest.
Palit’s new ThunderMaster has thorough upgrade from the previous version. It has more user-friendly interface as well as more personalized settings. With ThunderMaster, you can control your video card from overclock setting, fan speed to LED effect. You can also monitor GPU status with ThunderMaster utility.
AI-POWERED PERFORMANCE BOOST
AI rendering on dedicated Tensor Cores gives you incredible performance, pushing up frame rates and providing the headroom needed to maximize graphics settings and resolution, even up to 8K.
DLSS AI ACCELERATION
MAX FPS. MAX QUALITY. POWERED BY AI.
NVIDIA DLSS (Deep Learning Super Sampling) is groundbreaking AI rendering technology that increases graphics performance using dedicated Tensor Core AI processors on GeForce RTX™ GPUs. DLSS taps into the power of a deep learning neural network to boost frame rates and generate beautiful, sharp images for your games.
NVIDIA G-SYNC®
Get smooth, tear-free gameplay at high refresh rates, plus HDR and more. This is the ultimate gaming display and the go-to equipment for enthusiast gamers.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 3 |
Processor boost clock speed | 1470 MHz |
Processor frequency | 1042 MHz |
CUDA cores | 2304 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 3050 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 168 GB/s |
Data transfer rate | 14 Gbit/s |
Memory bus | 96 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 6 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1 |
DVI-D ports quantity | 1 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA Ansel | Yes |
NVIDIA GameStream | Yes |
NVIDIA G-SYNC | Yes |
Dual Link DVI | Yes |
HDCP | Yes |
Virtual Reality (VR) ready | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
PhysX | Yes |
Design | |
---|---|
Product colour | Black |
Number of slots | 2 |
Cooling type | Passive |
Power | |
---|---|
Power consumption (max) | 70 W |
Minimum system power supply | 300 W |
Weight & dimensions | |
---|---|
Depth | 166.3 mm |
Height | 137 mm |
Width | 38.3 mm |
Packaging data | |
---|---|
Package type | Box |
Manual | Yes |
STEP UP TO BRILLIANT PC GRAPHICS
Accelerate your entire PC experience with the fast, powerful NVIDIA® GeForce® GT 1030 graphics card. Gaming. HD video and picture editing. The GT 1030's award-winning NVIDIA Pascal™ architecture, powerful graphics engine, and state-of-the-art technologies give you the performance upgrade you need to drive today’s most demanding PC applications.
THE LATEST GAMING TECHNOLOGIES
Pascal is built to meet the demands of next generation displays. It features NVIDIA GameWorks™ technologies for extremely smooth gameplay and cinematic experiences.
PERFORMANCE
Pascal-powered graphics cards give you superior performance and power efficiency, built using ultra-fast FinFET and supporting DirectX™ 12 features to deliver the fastest, smoothest, most power-efficient gaming experiences.
GEFORCE EXPERIENCE
The easiest way to optimize your games and keep your drivers up to date, the GeForce Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you'll be able to update the driver directly, without leaving your desktop.
SMALL PACKAGE, BIG PUNCH
The power of a full size graphics card in an incredibly small package. MSI AERO ITX graphics cards are perfect for small form factor systems and HTPC’s as they only take up a fraction of the space of a full size graphics card. This means they will fit into virtually any system and ensure a smooth gaming experience.
PERFECT IN ANY CASE
The saying “Good things come in small packages” is certainly true for AERO ITX cards. Thanks to its small form factor it will fit into virtually any case. Its compact size also means that its weight is dramatically less than that of a full size graphics card.
MILITARY CLASS 4 COMPONENTS
One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for graphics cards. These components have proven durable enough to withstand the torturous circumstances of extreme gaming and overclocking for extended usage.
AFTERBURNER
MSI Afterburner is the world’s most recognized and widely used graphics card overclocking utility which gives you full control of your graphics cards. It also provides an incredibly detailed overview of your hardware and comes with some additional features such as customizing fan profiles, benchmarking and video recording.
Processor | |
---|---|
Parallel processing technology support | Not supported |
FireStream | No |
Processor boost clock speed | 1430 MHz |
Processor frequency | 1189 MHz |
CUDA cores | 384 |
CUDA | Yes |
Maximum resolution | 3840 x 2160 pixels |
Graphics processor | GeForce GT 1030 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory clock speed | 2100 MHz |
Memory bus | 64 bit |
Graphics card memory type | GDDR4 |
Discrete graphics card memory | 2 GB |
Ports & interfaces | |
---|---|
DVI-D ports quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 3.0 |
Performance | |
---|---|
Full HD | Yes |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.5 |
Shader model version | 5.0 |
DirectX version | 12.0 |
TV tuner integrated | No |
PhysX | Yes |
Design | |
---|---|
Product colour | Black |
Number of slots | 2 |
Form factor | Full-Height/Half-Length (FH/HL) |
Bracket height | Full-Height (FH) |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 20 W |
Minimum system power supply | 300 W |
System requirements | |
---|---|
Linux operating systems supported | Yes |
Windows operating systems supported | Yes |
General | |
---|---|
Product Family | AERO ITX |
Logistics data | |
---|---|
Harmonized System (HS) code | 84733020 |
Weight & dimensions | |
---|---|
Depth | 38 mm |
Height | 102 mm |
Width | 147 mm |
Weight | 281 g |
Packaging data | |
---|---|
Package weight | 507 g |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 lets VENTUS breeze through any task.
REVOLUTIONARY
DUAL-FAN THERMAL
Two fans on a huge heatsink ensures a cool and quiet experience.
CORE PIPE
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate to then spread heat along the full length of the heatsink.
COPPER BASEPLATE
Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.
TORX FAN 4.0
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Dual-Fan cooling system.
DrMos
DrMOS power stage solutions provide great efficiency with low power loss and enhanced voltage controls.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2505 MHz |
Processor frequency | 2520 MHz |
CUDA cores | 7168 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 1.2a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Silver |
Form factor | Full-Height/Half-Length (FH/HL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 220 W |
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 650 W |
Weight & dimensions | |
---|---|
Depth | 242 mm |
Height | 125 mm |
Width | 43 mm |
Weight | 680 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 998 g |
WINDFORCE COOLING SYSTEM
THE EVOLVING POWER OF WINDFORCE
The WINDFORCE cooling system features three 108mm newly designed bionic shark fans, alternate spinning, 9 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
COOLING, UPSCALED.
AORUS BIONIC FAN TECH
The sharks’ dermal denticles surrounding their body grant them significant advantages in fluid dynamics. Now AORUS features new Bionic Fan Tech that mimics the scale micro-surfacing and efficiently increases airflow by reducing micro turbulence.
DOUBLE BALL BEARING
The double ball bearing structure has better heat endurance and efficiency than sleeve structure.
DIRECTLY.
SO FAST.
LARGE VAPOR CHAMBER & HEAT-PIPE
The large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
THE OTHER WAY AROUND.
ALTERNATE SPINNING
Each fan rotates in different direction to the adjacent one. This special mechanism reduces turbulence and increases air pressure by minimizing the offset occurred between airflows.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
CHANNELED AIRFLOW.
ANGULAR FIN DESIGN
The angular and unequal fins height can channel the airflow through the fins and enlarge the contact surface.
MAKE ROOM FOR THE AIRFLOW.
SCREEN COOLING
To create more space for airflow to pass through, the heatsink extends over the PCB and therefore increase the ventilation. This Screen Cooling design provides better heat dissipation.
RGB FUSION
The legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER .
DUAL BIOS
The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
ANTI-SAG BRACKET
The new anti-sag bracket is tailored to each graphics card. It provides the optimized reinforcement and better overall visual appearance.
POWER INDICATOR
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
PCB COATING
Dust resistant - shields from dust, insects, dropped screws, drill shavings, and abrasion.
Moisture resistant - prevents unwanted conduction paths and board damage.
Corrosion resistant - protects from salt spray, humidity, and corrosion.
EXTREME OVERCLOCKING
The graphics card features excellent power phase design to allow the MOSFETs to operate at lower temperatures and provide a more stable voltage output. Load balancing of each MOSFET can effectively improve the overclocking performance and extend the life of the card.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
4-YEAR WARRANTY
We want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.
POWER THROUGH THE GAME
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory clock speed | 21000 MHz |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Grey |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 700 W |
General | |
---|---|
Product Family | AORUS |
Weight & dimensions | |
---|---|
Depth | 342 mm |
Height | 70.6 mm |
Width | 153 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2.97 kg |
Package height | 110 mm |
Package depth | 454 mm |
Package width | 273 mm |
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
LARGE COPPER PLATE & HEAT-PIPE
The large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
DUAL BIOS
The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
POWER INDICATOR
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
4-YEAR WARRANTY
We want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.
Power Through The Game
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory clock speed | 21000 MHz |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 700 W |
General | |
---|---|
Product Family | AERO |
Weight & dimensions | |
---|---|
Depth | 300 mm |
Height | 57.6 mm |
Width | 130 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.94 kg |
Package height | 85 mm |
Package depth | 398 mm |
Package width | 230 mm |
PERFORMANCE TO RULE YOUR GAME
GAME. STREAM. ADVANCE.
The AMD Radeon™ RX 7600 XT graphics card set a new level of performance for gamers. It features future-ready 16GB of GDDR6 memory, unified AMD RDNA™ 3 compute units, and next-generation technologies like AMD HYPR-RX, enabling ultra-fast and smooth gaming with ultra-detailed visuals for the best experience at 1080p, and the flexibility to jump up to 1440p.
The Radeon™ RX 7600 XT graphics card delivers an incredible high refresh gaming & streaming experience, and the confidence to game for years to come.
BUILT FOR THE GAMER
SPEEDSTER SERIES
The Speedster series exemplifies a modern aerodynamic style though clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
AIRFLOW AND COOLING
Finding the balance between a good looking card and maximizing it's performance is an art. Where we could improve airflow, we did it, we opened it up while keeping the design clean and cool.
XFX GHOST THERMAL
XFX's all new Ghost Thermal design cools your GPU better than ever before. Our new design features a straight through airflow venting to significantly improves cooling and compliments open design of the Ghost Thermal floating shroud design. Our 9 blade fans increase total air flow and provides long lasting quieter operation.
XFX DUAL BIOS READY
We know enthusiast like options, so for our QICK 308 RX 7600 series graphics cards we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
AMD RADIANCE DISPLAY™ ENGINE
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz.
XFX ZERO DB AUTO LOAD SENSING FANS
XFX Fans are equipped to run at the highest possible performance, while our Zero DB fan system will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY.
AMD FidelityFX™ Super Resolution (FSR) technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR) leverages FSR spatial upscaling technology on the driver level, giving you upscaled performance benefits across thousands of games.
ULTRA HD SUPPORT
The XFX RX 7600 XT is built for high-performance high definition gameplay. Experience smooth gameplay performance. With support for 8k you are ready for Next-Gen displays. See everything in mind blowing detail without sacrificing performance.
PERFORMANCE MADE EASY
Maximize performance and minimize input lag when you enable AMD HYPR-RX. AMD Fluid Motion Frames, AMD Radeon™ Super Resolution, AMD Radeon™ Boost, and AMD Radeon™ Anti-Lag technologies now work together to give you a boost in performance in an ever-growing collection of games.
AMD INFINITY CACHE
Breakthrough new levels of performance with up to 477 GB/s of effective memory bandwidth and blazing-fast clock speeds to deliver an incredible gaming experience.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
BREAKTHROUGH PERFORMANCE
AMD Radeon™ RX 7600 XT graphics card set a new level of performance for gamers and streamers. Featuring unified AMD RDNA™ 3 compute units, and blazing fast clock speeds, to enable advanced high refresh rate gaming performance at 1080p and beyond.
GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 16GB of advanced GDDR6 memory to provide high bandwidth performance, enabling high performance for today's most demanding games.
PCI EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput that enables two times the bandwidth when compared to PCIe® 3.0
500 MILLION GAMERS PLAY ON AMD RADEON
AMD Radeon™ graphics powers more than 500 million gamers on most of today’s newest gaming devices.
AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
Processor | |
---|---|
Stream processors | 2048 |
Parallel processing technology support | Not supported |
Ray accelerators | 32 |
Processor boost clock speed | 2810 MHz |
Processor frequency | 2029 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7600 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 477 GB/s |
Data transfer rate | 18 Gbit/s |
Number of pipelines | 4 |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
Dual Link DVI | No |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 600 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 11 |
Technical details | |
---|---|
Sustainability certificates | RoHS |
Weight & dimensions | |
---|---|
Depth | 302 mm |
Height | 114 mm |
Width | 50 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.55 kg |
Package height | 427 mm |
Package depth | 126 mm |
Package width | 214 mm |
PERFORMANCE TO RULE YOUR GAME
GAME. STREAM. ADVANCE.
The AMD Radeon™ RX 7600 XT graphics card set a new level of performance for gamers. It features future-ready 16GB of GDDR6 memory, unified AMD RDNA™ 3 compute units, and next-generation technologies like AMD HYPR-RX, enabling ultra-fast and smooth gaming with ultra-detailed visuals for the best experience at 1080p, and the flexibility to jump up to 1440p.
The Radeon™ RX 7600 XT graphics card delivers an incredible high refresh gaming & streaming experience, and the confidence to game for years to come.
BUILT FOR THE GAMER
SPEEDSTER SERIES
The Speedster series exemplifies a modern aerodynamic style though clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
AIRFLOW AND COOLING
Finding the balance between a good looking card and maximizing it's performance is an art. Where we could improve airflow, we did it, we opened it up while keeping the design clean and cool.
XFX GHOST THERMAL
XFX's all new Ghost Thermal design cools your GPU better than ever before. Our new design features a straight through airflow venting to significantly improves cooling and compliments open design of the Ghost Thermal floating shroud design. Our 9 blade fans increase total air flow and provides long lasting quieter operation.
XFX DUAL BIOS READY
We know enthusiast like options, so for our QICK 308 RX 7600 series graphics cards we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
AMD RADIANCE DISPLAY™ ENGINE
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz.
XFX ZERO DB AUTO LOAD SENSING FANS
XFX Fans are equipped to run at the highest possible performance, while our Zero DB fan system will also keep your fans running at efficient RPM in order to minimize annoying fan noise by lowering RPM all the way down to Zero RPM. When the heat is on during intense gaming, our fans will speed up as needed.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY.
AMD FidelityFX™ Super Resolution (FSR) technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR) leverages FSR spatial upscaling technology on the driver level, giving you upscaled performance benefits across thousands of games.
ULTRA HD SUPPORT
The XFX RX 7600 XT is built for high-performance high definition gameplay. Experience smooth gameplay performance. With support for 8k you are ready for Next-Gen displays. See everything in mind blowing detail without sacrificing performance.
PERFORMANCE MADE EASY
Maximize performance and minimize input lag when you enable AMD HYPR-RX. AMD Fluid Motion Frames, AMD Radeon™ Super Resolution, AMD Radeon™ Boost, and AMD Radeon™ Anti-Lag technologies now work together to give you a boost in performance in an ever-growing collection of games.
AMD INFINITY CACHE
Breakthrough new levels of performance with up to 477 GB/s of effective memory bandwidth and blazing-fast clock speeds to deliver an incredible gaming experience.
AMD SMART ACCESS MEMORY
Get more performance through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCI Express.
BREAKTHROUGH PERFORMANCE
AMD Radeon™ RX 7600 XT graphics card set a new level of performance for gamers and streamers. Featuring unified AMD RDNA™ 3 compute units, and blazing fast clock speeds, to enable advanced high refresh rate gaming performance at 1080p and beyond.
GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 16GB of advanced GDDR6 memory to provide high bandwidth performance, enabling high performance for today's most demanding games.
PCI EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput that enables two times the bandwidth when compared to PCIe® 3.0
500 MILLION GAMERS PLAY ON AMD RADEON
AMD Radeon™ graphics powers more than 500 million gamers on most of today’s newest gaming devices.
AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
Processor | |
---|---|
Stream processors | 2048 |
Parallel processing technology support | Not supported |
Ray accelerators | 32 |
Processor boost clock speed | 2755 MHz |
Processor frequency | 1980 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7600 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 477 GB/s |
Data transfer rate | 18 Gbit/s |
Number of pipelines | 4 |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
Dual Link DVI | No |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of slots | 2 |
Number of fans | 2 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 600 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 11 |
Technical details | |
---|---|
Sustainability certificates | RoHS |
Weight & dimensions | |
---|---|
Depth | 302 mm |
Height | 114 mm |
Width | 50 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.55 kg |
Package height | 427 mm |
Package depth | 126 mm |
Package width | 214 mm |
2x Fans. 2x Fun.
ASUS Dual Radeon™ RX 7600 XT fuses dynamic thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards — including two Axial-tech fans for maximizing airflow to the heatsink — are packed into the 22.7 cm long, 2.5-slot card, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.
Axial-tech Fan Design
Better, faster, stronger
Two tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure.
Auto-Extreme Technology
Precision automated manufacturing
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
GPU TWEAK III
Monitor, tweak, and tune
The ASUS GPU Tweak III utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.
Pair with a PSU
Use our wattage calculator to estimate how much power you’ll need to fuel your rig, and then pick a compatible ROG Thor, ROG Loki or ROG Strix AURA power supply for ultimate performance.
Processor | |
---|---|
Stream processors | 2048 |
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2513 MHz |
Processor boost clock speed (OC mode) | 2801 MHz |
Processor boost clock speed | 2781 MHz |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7600 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
HDCP version | 2.3 |
OpenGL version | 4.6 |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 2 fan(s) |
Cooling technology | ASUS Axial-tech |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 600 W |
General | |
---|---|
Product Family | Dual |
Weight & dimensions | |
---|---|
Depth | 123.2 mm |
Height | 49.6 mm |
Width | 227.2 mm |
Weight | 733 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.19 kg |
Package height | 68 mm |
Package depth | 220.5 mm |
Package width | 368 mm |
Manual | Yes |
Make your entire PC experience faster with the new Palit GeForce® GT 710 dedicated graphics card. Now, you can enjoy up to 10x better performance than integrated graphics in all your PC multimedia applications.
ThunderMaster
ThunderMaster is a utility program for the graphics card under Windows, and provides you to boost performance of the graphics card and to monitor the GPU information, which will only function correctly in conjunction with your new graphics adapter.
Processor | |
---|---|
Maximum analog resolution | 2048 x 1536 pixels |
Maximum digital resolution | 2560 x 1600 pixels |
Processor frequency | 954 MHz |
CUDA cores | 192 |
CUDA | Yes |
Maximum resolution | 2560 x 1600 pixels |
Graphics processor | GeForce GT 710 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 12.8 GB/s |
Memory clock speed | 1600 MHz |
Memory bus | 64 bit |
Graphics card memory type | GDDR3 |
Discrete graphics card memory | 2 GB |
Ports & interfaces | |
---|---|
VGA (D-Sub) ports quantity | 1 |
DVI-D ports quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express x8 2.0 |
Performance | |
---|---|
Full HD | Yes |
NVIDIA 3D Vision | Yes |
Dual Link DVI | Yes |
HDCP | No |
OpenGL version | 4.5 |
DirectX version | 12.0 |
TV tuner integrated | No |
PhysX | Yes |
Design | |
---|---|
Product colour | Black, Metallic |
Number of slots | 2 |
Cooling type | Passive |
Power | |
---|---|
Power consumption (typical) | 19 W |
Minimum system power supply | 300 W |
System requirements | |
---|---|
Windows operating systems supported | Yes |
Logistics data | |
---|---|
Harmonized System (HS) code | 84733020 |
Weight & dimensions | |
---|---|
Depth | 115 mm |
Height | 69 mm |
Packaging data | |
---|---|
Manual | Yes |
Polychrome SYNC
Create your own unique colorful light effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
Triple Fan Design
Triple fan design helps to optimize system cooling to reduce the operating temperature.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Striped Axial Fan
Designed For Enhanced Airflow.
ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
AMD Eyefinity Technology
AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
Experience unprecedented performance, visuals, and efficiency for gaming and streaming in 1080p with the AMD Radeon™ RX 7600 graphics card, powered by RDNA™ 3 architecture. Immerse yourself in breathtaking visuals with the pinpoint color accuracy of AMD Radiance Display™ Engine and boost frame rates with AMD FidelityFX™ Super Resolution and Radeon™ Super Resolution upscaling technologies.1,2 To unlock even more performance, combine AMD Radeon™ RX 7000 Series graphics card with a compatible AMD Ryzen™ processor to activate AMD smart technologies.3
BREAKTHROUGH PERFORMANCE
AMD Radeon™ RX 7600 graphics card set a new level of performance for gamers and streamers. Featuring unified AMD RDNA™ 3 compute units, and blazing fast clock speeds, to enable advanced high refresh rate gaming performance at 1080p.
BREATHTAKING VISUALS
Discover new levels of fidelity and ultra-fast gameplay with High-Performance Rendering, a combination of compute-based AMD FideltyFX™ features and upscaling technologies, to deliver world-class visuals with remarkable performance. Further immerse yourself with the AMD Radiance Display™ Engine and DisplayPort™ 2.14 to experience up to 68 billion colors for video playback at up to 8K. Deliver enhanced visual quality to your audience when streaming and recording using the improved encoders, together with integrated AI and content adaptive machine learning technology to enable better looking and crisper visuals when streaming.
BETTER TOGETHER
Combine an AMD Radeon™ RX 7600 graphics card and AMD Ryzen™ processors to activate AMD smart technologies3. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon™ RX 7000 Series graphics card with the AMD Software: Adrenalin Edition™ application, featuring bulletproof drivers, for the best PC gaming experiences.
UPSIZE PERFORMANCE.
MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology1 takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games.
AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2725 MHz |
Processor frequency | 2320 MHz |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7600 |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 8 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x8 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Number of slots | 2.25 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Minimum system power supply | 600 W |
Weight & dimensions | |
---|---|
Depth | 303 mm |
Height | 131 mm |
Width | 45 mm |
Weight | 834 g |
Packaging data | |
---|---|
Package type | Box |
User guide | Yes |
Gaming Unbound
GAMING SLIM series is a thinner variant of GAMING series while maintaining high performance capabilities and aggressive looks
HASSLE-FREE COMPATIBILITY
Lightened design is made for those building a gaming rig with space constraints.
Elevate performance with TRI FROZR 3 cooling and its key features – TORX FAN 5.0, Core Pipe, and Airflow Control.
TRI FROZR 3 THERMAL DESIGN
Stay cool and quiet. MSI’s TRI FROZR 3 thermal design enhances heat dissipation all around the graphics card.
TORX FAN 5.0
TORX FAN 5.0 is a culmination of fan design improvements to increase the air pressure and flow into the heatsink. Ring arcs link three sets of fan blades that tilt 22 degrees together to maintain high-pressure airflow even at slower rotational speeds. The resulting increased airflow is +23% compared to an axial fan.
AIRFLOW CONTROL
Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors design for optimizing the balance between cooling and quieter acoustics.
ELEVATED DETAILS
Take a closer look at the other thermal solution features that help to control temperatures and the noise level.
UNRESTRICTED COOLING
A large airflow vent on the backplate allows exhaust air to pass through directly.
DOUBLE BALL BEARING
Two sets of durable ball bearings spin the TORX FANs for years of intense and lengthy gaming sessions.
ZERO FROZR
The fans completely stop when temperatures are relatively low, eliminating all noise.
YOUR SUPPORT CHARACTER
A bundled support bracket can be attached to your PC case for additional graphics card reinforcement.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2730 MHz |
Processor frequency | 2745 MHz |
CUDA cores | 7680 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 Ti |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 1.2a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | No |
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | MSI TORX FAN 5.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 285 W |
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 700 W |
General | |
---|---|
Product Family | GAMING |
Weight & dimensions | |
---|---|
Depth | 307 mm |
Height | 51 mm |
Width | 125 mm |
Weight | 1.09 kg |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.84 kg |
Big Productivity in a Small Package
The ASUS GeForce® GT 730 is a passively-cooled single-slot graphics card that enables quiet multi-monitor productivity
COOLING
Passive Cooling
A passively-cooled design creates a quieter workspace.
ENGINEERING
4x HDMI Ports
Enable multi-monitor productivity with support for up to 4 external displays connected to the built-in HDMI ports.
Single-slot Design
A compact design increases compatibility with other PCIe peripherals and even allows multiple ASUS GT730s to be stacked in a single system.
Auto−Extreme Technology
Precision automated manufacturing
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
SOFTWARE
GPU Tweak II
Monitor, tweak, and tune
The ASUS GPU Tweak II utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed (OC mode) | 927 MHz |
Processor boost clock speed | 902 MHz |
CUDA cores | 384 |
CUDA | Yes |
Maximum resolution | 3840 x 2160 pixels |
Graphics processor | GeForce GT 730 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory clock speed | 5010 MHz |
Graphics card memory type | GDDR5 |
Discrete graphics card memory | 2 GB |
Ports & interfaces | |
---|---|
HDMI version | 1.4b |
HDMI ports quantity | 4 |
Interface type | PCI Express x1 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Blue |
Number of slots | 1 |
Cooling type | Passive |
Power | |
---|---|
Minimum system power supply | 300 W |
Logistics data | |
---|---|
Harmonized System (HS) code | 84733020 |
Weight & dimensions | |
---|---|
Depth | 105 mm |
Height | 18 mm |
Width | 148 mm |
Packaging data | |
---|---|
Package type | Box |
Manual | Yes |
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 110mm unique blade fans, alternate spinning, 10 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink design allows air flow to pass through, providing better heat dissipation.
LARGE VAPOR CHAMBER & HEAT-PIPE
The large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
DUAL BIOS
The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
POWER INDICATOR
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
ANTI-SAG BRACKET
The new anti-sag bracket is tailored to each graphics card. It provides the optimized reinforcement and better overall visual appearance.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
4-YEAR WARRANTY
We want you to experience the best service you have ever had. This is why, on top of our standard 3-year warranty, we would like to offer you an additional 1 year of protection to your graphics card free of charge. You can enjoy a 4-year warranty by registering on the website within 30 days of purchase.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA cores | 16384 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4090 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory clock speed | 2100 MHz |
Memory bus | 384 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 24 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12.0 |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 1000 W |
General | |
---|---|
Product Family | AERO |
Weight & dimensions | |
---|---|
Depth | 342 mm |
Height | 75 mm |
Width | 150 mm |
Packaging data | |
---|---|
Package type | Box |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 and Airflow Control lets VENTUS breeze through any task.
REVOLUTIONARY
DUAL-FAN THERMAL
Two fans on a huge heatsink ensures a cool and quiet experience.
CORE PIPE
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate to then spread heat along the full length of the heatsink.
COPPER BASEPLATE
Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.
AIRFLOW CONTROL
Stay stealthy with Airflow Control which improves airflow dynamics. Deflectors provide additional surface area and guide air to where it’s needed for maximum cooling.
TORX FAN 4.0
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Dual-Fan cooling system.
DrMos
DrMOS power stage solutions provide great efficiency with low power loss and enhanced voltage controls.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
BRINGING IT ALL TOGETHER
MSI's exclusive MSI Center software helps you get the most out of your MSI products. Monitor, tweak, and optimize in real-time with just a few clicks.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2640 MHz |
Processor frequency | 2685 MHz |
CUDA cores | 8448 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 Ti SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 1.2a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Silver |
Form factor | Full-Height/Half-Length (FH/HL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 285 W |
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 700 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 242 mm |
Height | 125 mm |
Width | 51 mm |
Weight | 882 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.21 kg |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 and Airflow Control lets VENTUS breeze through any task.
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 2x AI performance
Third-Gen RT Cores
Up to 2x ray tracing performance
REVOLUTIONARY
TRIPLE-FAN THERMAL
Three fans on a huge heatsink ensures a cool and quiet experience.
Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate to then spread heat along the full length of the heatsink.
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Triple-Fan cooling system.
Stay stealthy with Airflow Control which improves airflow dynamics. Deflectors provide additional surface area and guide air to where it’s needed for maximum cooling.
DrMos
DrMOS power stage solutions provide great efficiency with low power loss and enhanced voltage controls.
2 Oz Copper
A thickened copper layer inside the PCB increases conductivity which improves heat dissipation and reliability.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
Sheet-Metal Anti-Bending
A sheet-metal anti-bending plate reinforces the whole card while thermal pads allow cooling to reach critical component underneath.
Support Bracket
A bundled support bracket can be attached to your PC case for additional graphics card reinforcement.
BRINGING IT ALL TOGETHER
MSI's exclusive MSI Center software helps you get the most out of your MSI products. Monitor, tweak, and optimize in real-time with just a few clicks.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA cores | 9728 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4080 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 22.4 GB/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Silver |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 322 mm |
Height | 63 mm |
Width | 136 mm |
Weight | 1.59 kg |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2.2 kg |
WINDFORCE
COOLING SYSTEM
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
LARGE COPPER PLATE & HEAT-PIPE
The large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
Power Through The Game
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 Ti SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory clock speed | 21000 MHz |
Memory bus | 256 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 750 W |
Weight & dimensions | |
---|---|
Depth | 261 mm |
Height | 50 mm |
Width | 126 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.51 kg |
Package height | 75 mm |
Package depth | 322 mm |
Package width | 214 mm |
MSI GeForce RTX™ 4060 GAMING X 8G
Game, stream, create. The GeForce RTX™ 4060 lets you take on the latest games and apps with the ultra-efficient NVIDIA Ada Lovelace architecture. Experience immersive, AI-accelerated gaming with ray tracing and DLSS 3, and supercharge your creative process and productivity with NVIDIA Studio.
GAMING IN STYLE!
Play with style! GAMING is upgraded with TWIN FROZR 9 to sustain intense performance during gaming and content creation. A high-speed style matches high-performance capabilities for gamers who want to go all out.
STRENGTH AND ARTISTRY
MSI envisioned the GAMING series as the favored graphic cards solution for all sorts of gamers, including adventure seekers, esport competitors, livestream broadcasters, and more. GAMING reflects both the spirit of gamers and the intense performance within the cards with a styled exterior that erupts with colorful lights between bold lines and edges.
TWIN FROZR 9 THERMAL DESIGN:
Stay cool and quiet. MSI’s TWIN FROZR 9 thermal design enhances heat dissipation all around the graphics card.
TORX FAN 5.0:
TORX FAN 5.0 is a culmination of fan design improvements to increase the air pressure and flow into the heatsink. Ring arcs link three sets of fan blades that tilt 22 degrees together to maintain high-pressure airflow even at slower rotational speeds. The resulting increased airflow is +23% compared to an axial fan.
A fan cowl extends a bit beyond the general enclosure to lengthen the wind’s passageway, allowing airflow to stabilize and move smoother through the fans. Bulging notches under the cowl help to reduce recirculation, thus further improving airflow stability and reducing some noise.
COPPER BASEPLATE:
Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.
KEEPING THE CORE COOL:
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate and spread the heat along the full length of the heatsink.
Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors for optimizing the balance between cooling and quieter acoustics.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2595 MHz |
Processor frequency | 2610 MHz |
CUDA cores | 3072 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4060 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Data transfer rate | 17 Gbit/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 8 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | No |
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Grey |
Illumination | Yes |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX FAN 5.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 115 W |
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 550 W |
General | |
---|---|
Product Family | GAMING |
Weight & dimensions | |
---|---|
Depth | 130 mm |
Height | 41 mm |
Width | 247 mm |
Weight | 587 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1 kg |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 lets VENTUS breeze through any task.
REVOLUTIONARY
DUAL-FAN THERMAL
Two fans on a huge heatsink ensures a cool and quiet experience.
TORX FAN 4.0
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Dual-Fan cooling system.
GAMING MODE
Get Ready to Game
Create game profiles with personalized graphics card settings including performance, True Color, and more.
DrMos
DrMOS power stage solutions provide great efficiency with low power loss and enhanced voltage controls.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2610 MHz |
CUDA cores | 4352 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4060 Ti |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | No |
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Form factor | Full-Height/Half-Length (FH/HL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 165 W |
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 550 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 120 mm |
Height | 42 mm |
Width | 595 mm |
Weight | 199 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 832 g |
WINDFORCE
COOLING SYSTEM
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
LARGE COPPER PLATE & HEAT-PIPE
The large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
RGB FUSION
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
DUAL BIOS
The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
POWER INDICATORS
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
Power Through The Game
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 Ti SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory clock speed | 21000 MHz |
Memory bus | 256 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | EAGLE |
Weight & dimensions | |
---|---|
Depth | 261 mm |
Height | 50 mm |
Width | 126 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.52 kg |
Package height | 75 mm |
Package depth | 322 mm |
Package width | 214 mm |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 lets VENTUS breeze through any task.
REVOLUTIONARY
DUAL-FAN THERMAL
Two fans on a huge heatsink ensures a cool and quiet experience.
TORX FAN 4.0
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Dual-Fan cooling system.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2490 MHz |
Processor frequency | 2505 MHz |
CUDA cores | 3072 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4060 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Data transfer rate | 17 Gbit/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 8 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 115 W |
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 550 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 199 mm |
Height | 41 mm |
Width | 120 mm |
Weight | 546 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 783 g |
Gaming Unbound
GAMING SLIM series is a thinner variant of GAMING series while maintaining high performance capabilities and aggressive looks.
HASSLE-FREE COMPATIBILITY
Lightened design is made for those building a gaming rig with space constraints.
STRENGTHAND MASTERY
Elevate performance with TRI FROZR 3 cooling and its key features – TORX FAN 5.0, Core Pipe, and Airflow Control.
TRI FROZR 3 THERMAL DESIGN
Stay cool and quiet. MSI’s TRI FROZR 3 thermal design enhances heat dissipation all around the graphics card.
AIRFLOW CONTROL
Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors design for optimizing the balance between cooling and quieter acoustics.
ELEVATED DETAILS
Take a closer look at the other thermal solution features that help to control temperatures and the noise level.
UNRESTRICTED COOLING
A large airflow vent on the backplate allows exhaust air to pass through directly.
DOUBLE BALL BEARING
Two sets of durable ball bearings spin the TORX FANs for years of intense and lengthy gaming sessions.
ZERO FROZR
The fans completely stop when temperatures are relatively low, eliminating all noise.
YOUR SUPPORT CHARACTER
A bundled support bracket can be attached to your PC case for additional graphics card reinforcement.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2640 MHz |
Processor frequency | 2655 MHz |
CUDA cores | 7168 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 SUPER |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 1.2a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | No |
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Silver |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | MSI TORX FAN 5.0 |
Cooling type | Active |
Power | |
---|---|
Power supply location | External |
Power consumption (typical) | 245 W |
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 650 W |
General | |
---|---|
Product Family | GAMING |
Weight & dimensions | |
---|---|
Depth | 307 mm |
Height | 125 mm |
Width | 46 mm |
Weight | 972 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 972 g |
LOW PROFILE DESIGN
Low profile design with one slot and 150mm card length saves more spaces to fit slim or smaller system. Equipped with a DVI-D and a HDMI port, the card supports up to 4K high resolution.
ULTRA DURABLE COMPONENTS
Engineered with the high-quality chokes and capacitors, this graphic card delivers outstanding performance and durable system lifespan.
SMOOTH AND CRISP VISUAL
Equipped with a DVI-D and a HDMI port, the card can deliver beautiful and smooth 4K video playback.
Intuitive AORUS Graphics Engine Utility
The cutting edge intuitive interface allows you to tune the clock speeds, voltage, fan performance, and power target in real-time according to your own gaming requirement.
One-click Overclocking
With a simple click on AORUS Graphics Engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge
Processor | |
---|---|
Parallel processing technology support | Not supported |
FireStream | No |
Processor boost clock speed | 1506 MHz |
Processor frequency | 1257 MHz |
CUDA | Yes |
Maximum resolution | 4096 x 2160 pixels |
Graphics processor | GeForce GT 1030 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory clock speed | 6008 MHz |
Memory bus | 64 bit |
Graphics card memory type | GDDR5 |
Discrete graphics card memory | 2 GB |
Ports & interfaces | |
---|---|
HDMI version | 2.0b |
DVI-D ports quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 3.0 |
Performance | |
---|---|
Full HD | Yes |
NVIDIA G-SYNC | No |
NVIDIA GameWorks VR | No |
NVIDIA 3D Vision | No |
Dual Link DVI | Yes |
HDCP | Yes |
OpenGL version | 4.5 |
Shader model version | 5.1 |
DirectX version | 12.0 |
TV tuner integrated | No |
PhysX | Yes |
Design | |
---|---|
Product colour | Black |
Number of slots | 1 |
Form factor | Half-Height/Half-Length (HH/HL) |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power | |
---|---|
Minimum system power supply | 300 W |
System requirements | |
---|---|
Linux operating systems supported | Yes |
Windows operating systems supported | Yes |
Weight & dimensions | |
---|---|
Depth | 14.7 mm |
Height | 68.9 mm |
Width | 149.9 mm |
TAKE THE ESSENTIALS
VENTUS brings a fundamentally solid experience to users looking for a performance graphics card. A sharp-looking updated design with TORX FAN 4.0 and Airflow Control lets VENTUS breeze through any task.
REVOLUTIONARY
DUAL-FAN THERMAL
Two fans on a huge heatsink ensures a cool and quiet experience.
CORE PIPE
Core Pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touch the GPU baseplate to then spread heat along the full length of the heatsink.
COPPER BASEPLATE
Heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.
AIRFLOW CONTROL
Stay stealthy with Airflow Control which improves airflow dynamics. Deflectors provide additional surface area and guide air to where it’s needed for maximum cooling.
TORX FAN 4.0
TORX FAN 4.0 is built on teamwork, with pairs of fan blades bound together with a linked outer ring design that focuses airflow into the Dual-Fan cooling system.
DrMos
DrMOS power stage solutions provide great efficiency with low power loss and enhanced voltage controls.
Fuse
Additional fuses built into the custom PCB provide additional safeguards against electrical damage.
Processor | |
---|---|
Maximum displays per videocard | 4 |
Processor boost clock speed | 2640 MHz |
CUDA cores | 7680 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 Ti |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | No |
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black, Silver |
Illumination | Yes |
Form factor | Full-Height/Half-Length (FH/HL) |
Number of fans | 2 fan(s) |
Cooling technology | MSI TORX Fan 4.0 |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 285 W |
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 700 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 242 mm |
Height | 125 mm |
Width | 51 mm |
Weight | 869 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.22 kg |
TURING SHADERS
The new GeForce GTX 1660-GDDR6 has Turing encoder. Featuring concurrent execution of floating point and integer operations, adaptive shading technology, and a new unified memory architecture with twice the cache of its predecessor. Get 1.4X power efficiency over previous generation for a faster, cooler and quieter gaming experience that take advantage of Turing’s advanced graphics features.
AWESOME PERFORMANCE
Easily upgrade your PC and get game ready with performance that’s up to 2X the GeForce GTX 950 and up to 70% faster than the GTX 1050 on the latest games.
GEFORCE EXPERIENCE
Capture and share videos, screenshots, and livestreams with friends. Keep your GeForce drivers up to date. And optimize your game settings. GeForce Experience™ lets you do it all. It's the essential companion to your GeForce graphics card.
PREMIUM DESIGN
A fresh new dual fan design, VENTUS proudly displays its industrial shapes in neutral colors to fit any build.
EFFECTIVE COOLING DESIGN
Aluminum extruded heat sink maximizes direct contact area with the GPU and memory in order to transfer heat efficiently. Enhances heat dissipation by guiding the airflow to PCB through heat sink sections.
Processor | |
---|---|
Maximum displays per videocard | 3 |
Processor boost clock speed | 1620 MHz |
CUDA cores | 896 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce GTX 1660 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 4 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4 |
HDMI version | 2.0b |
DVI-D ports quantity | 1 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 3.0 |
Performance | |
---|---|
NVIDIA Ansel | Yes |
NVIDIA G-SYNC | Yes |
Dual Link DVI | Yes |
HDCP | Yes |
Virtual Reality (VR) ready | Yes |
OpenGL version | 4.6 |
DirectX version | 12.0 |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of fans | 2 fan(s) |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 90 W |
Supplementary power connectors | 1x 6-pin |
Minimum system power supply | 300 W |
General | |
---|---|
Product Family | VENTUS |
Weight & dimensions | |
---|---|
Depth | 179 mm |
Height | 112 mm |
Width | 42 mm |
Weight | 480 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 688 g |
