WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 90mm unique blade fans, alternate spinning, 4 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
RGB FUSION
The legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.
DUAL BIOS
The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
POWER INDICATOR
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
BUILT STRONG
ULTRA DURABLE
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
FRIENDLY PCB DESIGN
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor frequency | 2565 MHz |
CUDA cores | 5888 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Data transfer rate | 21 Gbit/s |
Number of pipelines | 4 |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
NVIDIA 3D Vision | No |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Multi |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Fan diameter | 9 cm |
Number of fans | 3 fan(s) |
Cooling technology | GIGABYTE WINDFORCE 3X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 650 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | GAMING |
Weight & dimensions | |
---|---|
Depth | 300 mm |
Height | 50.2 mm |
Width | 130 mm |
Packaging data | |
---|---|
Package type | Box |
User guide | Yes |
New Atmosphere of Hellhound
Hellhound has long been guarding the gaming underworld and is committed to deliver the most reliable gaming experience. Remain simple and sleek; it is never humble in showing its strength when the gamers calls for. The Hellhound of this generation features a second LED color – amethyst purple—to provide a different atmosphere in your PC build.
Engineered for Performance and Reliability
The PowerColor Hellhound RX 7900 XTX adopts a triple ringed-fan solution (100 x 90 x 100mm), a set of 8 x 6φ heatpipes running through the heatsink, and a copper plate directly touching the GPU while covering VRAM to achieve better cooling efficiency. In addition, the product is built with 12+3+2+2+1 phase VRM design and DrMOS that comes with IMON real-time digital monitoring, aiming at providing reliable performance output during gaming.
High Quality Japanese Dual Ball Bearings
Dual ball bearings reduce rotational friction, providing excellent heat dissipation and effectively doubling the expected lifetime of the fans.
Intelligent Fan Controller
Utilizing temperature detection from a smart chip, fans will start running when the GPU reaches 60℃ and shut down below 50℃. Efficient cooling, fan-noise reduction, and extended product lifetime are all benefits of a more accurate temperature monitoring.
Unprecedented Ring-fan Blade Design
The newest 9-blade design of our fans generate better airflow and air pressure under the same noise level, improving cooling performance to reduce GPU temperatures by more than 3℃ compared to previous generations.
GPU Direct-Contact Copper Plate
We have increased the copper plate area to provide direct contact with the GPU while covering VRAM to increase the heat transfer threshold to the max.
Vertical Fin Heatsink
A large heatsink with vertical fins spaced closely is mounted on PCB and offers better heat-spread area and radiation, allowing airflow to disperse heat efficiently.
Turbulence Reducing Fan Rotation
The middle fan spins in the reverse way so as to reduce the air turbulence between neighboring fans when drawing in cool air. The mechanism therefore maximizes the air flow and pressure when less turbulence occurs to offset, further to lower the noise level without sacrificing the cooling efficiency.
Optimum Heatpipe Arrangement
A set of 8 x 6φ nickel-plated copper heatpipes align closely above the PCB to more quickly and effectively transfer heat from the GPU and VRAM to the cooling array.
Car-Grade Power Module DrMOS with iMON Real Time Digital Monitoring
Hellhound adopts a 12+3+2 phase VRM design with DrMOS to power the GPU as well as an additional 2+1 phase specifically designated for the VRAM. New IMON technology monitors and reports the electric current and power consumption on each individual phase. By balancing the workload, the Hellhound ensures unparalleled stability and thermal protection during overclocking.
In addition, high quality car-grade polymer capacitors features long-lasting durability and high conductivity lowers power loss during transmission.
High Quality PCB Design
A premium 14-layer high TG PCB Board -including a 2 oz power layer- is utilized in the Hellhound RX 7900 XTX; a PCB such designed decreases signal loss during transmission: important especially for higher-end GPUs with increased demands for higher currents and stability.
Anti-Sag Bracket
A robust metal bracket is installed on the side of the PCB and is supported all the way to the I/O plate, making the card stand firmly in place inside the chassis.
Metal Reinforced Backplate
The metal backplate strengthens and protects the internal components from PCB bend, and a cut-out design on the back plate allows exhaust heat to properly flow through for heat-dissipation efficiency.
Brand New Amethyst LED Color
Hellhound of this generation comes with a brand new amethyst purple LED lighting while retaining the previous ice blue. Gamers are able to choose the color they want by flipping the switch on side of the card.
Ice blue shows coolness and elegance while amethyst represents mystery and charm.
Dual BIOS Mode
Hellhound RX 7900 XTX features Dual BIOS built-in and a switch for easy swapping.
- OC BIOS: A boosted mode that increases fan RPM to keep your card operating at a lower temperature to drive higher performance.
- Silent BIOS: Focused on lower noise and fan longevity, a milder fan speed, trading fan speed and noise for moderate, but still controlled, temperatures while maintaining performance.
THE MOST ADVANCED GRAPHICS FOR GAMERS
Experience unprecedented performance, visuals, and efficiency at 4K and beyond with AMD Radeon™ RX 7000 Series graphics cards, the world's first gaming GPUs powered by AMD RDNA™ 3 chiplet technology. Immerse yourself in breathtaking visuals with the pinpoint color accuracy of AMD Radiance Display™ Engine and boost frame rates with AMD FidelityFX™ Super Resolution and Radeon™ Super Resolution upscaling technologies. To unlock even more performance, combine AMD Radeon™ RX 7000 Series graphics and compatible AMD Ryzen™ processors to activate AMD smart technologies.
BREAKTHROUGH PERFORMANCE
AMD Radeon™ RX 7000 Series graphics cards set a new standard for ultra-enthusiast class gaming performance. Featuring advanced AMD RDNA™ 3 compute units, blazing fast clock speeds, and chiplet technology to enable fluid, high-refresh rate gaming experiences. Breakthrough new levels of performance with up to 24GB of GDDR6 memory and 2nd generation AMD Infinity Cache™ to deliver an incredible experience at 4K and beyond.
BREATHTAKING VISUALS
Discover new levels of fidelity and ultra-fast gameplay with High-Performance Rendering, a combination of compute-based AMD FideltyFX™ features and upscaling technologies, to deliver world-class visuals with remarkable performance. Further immerse yourself with the AMD Radiance Display™ Engine and DisplayPort™ 2.1 to experience up to 68 billion colors at up to 8K 165Hz.
BETTER TOGETHER
Combine AMD Radeon™ RX 7000 Series graphics cards and AMD Ryzen™ processors to activate AMD smart technologies. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon™ RX 7000 Series GPU with the AMD Software: Adrenalin Edition™ application, featuring bulletproof drivers, for the best PC gaming experiences.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
AMD FidelityFX™ Super Resolution Technology
AMD FidelityFX™ Super Resolution technology, or FSR, uses cutting-edge super-optimized spatial upscaling technology to generate super high-quality edges and distinctive pixel detail. With FSR, turn on the latest features and settings in your games while maintaining an acceptable framerate.
Optimized for Windows 11
AMD Radeon™ RX 7000 Series Graphics power the ultimate Windows 11 gaming experience with optimized support for DirectX® 12 Ultimate, AutoHDR, and DirectStorage.
AMD RDNA™ 3 Architecture with Hardware Raytracing
The AMD RDNA™ 3 architecture features industry-advancing chiplet technology to deliver next-generation performance, visuals, and power efficiency. Discover new levels of performance with advanced AMD RDNA™ 3 compute units, featuring redesigned raytracing accelerators for incredible performance while improving image quality.
AMD FreeSync™ Technology
Take full advantage of the AMD Radeon™ RX 7000 Series graphics cards by pairing with a certified AMD FreeSync™ technology-enabled monitor to enable an exceptional stutter and tear-free gaming experience with high refresh rates, low latency, and stunning HDR.
Processor | |
---|---|
Stream processors | 6144 |
Processor frequency (OC mode) | 2525 MHz |
Processor boost clock speed | 2500 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7900 XTX |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 20 Gbit/s |
Number of pipelines | 8 |
Memory bus | 384 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 24 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
Dual Link DVI | No |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Blue, Purple |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 800 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 11 |
Weight & dimensions | |
---|---|
Depth | 338 mm |
Height | 147 mm |
Width | 62 mm |
Packaging data | |
---|---|
Package type | Box |
Hellhound Series: Unleash the Power
Introducing the Hellhound models for the 7800 XT and 7700 XT series - where raw power meets sleek design. Tailored for the gaming elite, the Hellhound cards come equipped with an advanced cooling system and high-performance components, ensuring that gamers can dive deep into intense gaming sessions without a hitch.
Engineered for Uncompromising Performance and Durability
The PowerColor 7800 XT Hellhound is meticulously crafted for durability and performance. Its metal-reinforced backplate adds a layer of protection and rigidity, while the Dual BIOS feature offers seamless adaptability between performance modes. Built on a high-quality 14-layer PCB, the card promises enhanced signal quality and longevity.
High Quality Japanese Dual Ball Bearings
Dual ball bearings reduce rotational friction, providing excellent heat dissipation and effectively doubling the expected lifetime of the fans.
Intelligent Fan Controller
Utilizing temperature detection from a smart chip, fans will start running when the GPU reaches 60℃ and shut down below 50℃. Efficient cooling, fan-noise reduction, and extended product lifetime are all benefits of a more accurate temperature monitoring.
Unprecedented Ring-fan Blade Design
The newest 9-blade design of our fans generate better airflow and air pressure under the same noise level, improving cooling performance to reduce GPU temperatures by more than 3℃ compared to previous generations.
GPU Direct-Contact Copper Plate
We have increased the copper plate area to provide direct contact with the GPU while covering VRAM to increase the heat transfer threshold to the max.
Vertical Fin Heatsink
A large heatsink with vertical fins spaced closely is mounted on PCB and offers better heat-spread area and radiation, allowing airflow to disperse heat efficiently.
Turbulence Reducing Fan Rotation
The middle fan spins in the reverse way so as to reduce the air turbulence between neighboring fans when drawing in cool air. The mechanism therefore maximizes the air flow and pressure when less turbulence occurs to offset, further to lower the noise level without sacrificing the cooling efficiency.
Optimum Heatpipe Arrangement
A set of 5 x 6φ nickel-plated copper heatpipes align closely above the PCB to more quickly and effectively transfer heat from the GPU and VRAM to the cooling array.
Car-Grade Power Module DrMOS with iMON Real Time Digital Monitoring
Hellhound adopts a 9+2+1 phase VRM design with DrMOS to power the GPU as well as an additional 2+1 phase specifically designated for the VRAM. New IMON technology monitors and reports the electric current and power consumption on each individual phase. By balancing the workload, the Hellhound ensures unparalleled stability and thermal protection during overclocking.
In addition, high quality car-grade polymer capacitors features long-lasting durability and high conductivity lowers power loss during transmission.
High Quality PCB Design
A premium 14-layer high TG PCB Board -including a 2 oz power layer- is utilized in the Hellhound RX 7800 XT; a PCB such designed decreases signal loss during transmission: important especially for higher-end GPUs with increased demands for higher currents and stability.
Metal Reinforced Backplate
The metal backplate strengthens and protects the internal components from PCB bend, and a cut-out design on the back plate allows exhaust heat to properly flow through for heat-dissipation efficiency.
Brand New Amethyst LED Color
Hellhound of this generation comes with a brand new amethyst purple LED lighting while retaining the previous ice blue. Gamers are able to choose the color they want by flipping the switch on side of the card.
Ice blue shows coolness and elegance while amethyst represents mystery and charm.
Dual BIOS Mode
Hellhound RX 7800 XT features Dual BIOS built-in and a switch for easy swapping.
-OC BIOS: A boosted mode that increases fan RPM to keep your card operating at a lower temperature to drive higher performance.
-Silent BIOS: Focused on lower noise and fan longevity, a milder fan speed, trading fan speed and noise for moderate, but still controlled, temperatures while maintaining performance.
GAME.
STREAM.
ADVANCE.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
GAME
The AMD Radeon™ RX 7800 XT graphics cards set a new level of performance for gamers. Featuring up to 16GB of GDDR6 memory, unified AMD RDNA™ 3 compute units, and next-generation features to enable ultra-fast, ultra-smooth gaming performance at 1440p, and the flexibility to experience ultra-detailed graphics at 4K. Immerse yourself even further with the AMD Radiance Display™ Engine and DisplayPort™ 2.1 to experience up to 68 billion colors for video playback and support for up to 8K.
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
ADVANCE
Combine AMD Radeon™ RX 7700 XT and 7800 XT graphics cards with AMD Ryzen™ processors to activate AMD smart technologies. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon™ RX 7000 Series graphics cards with the AMD Software: Adrenalin Edition™ application, featuring bulletproof drivers, for the best PC gaming experiences.
UPSIZE PERFORMANCE.
MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Optimized for Windows 11
AMD Radeon™ RX 7000 Series Graphics power the ultimate Windows 11 gaming experience with optimized support for DirectX® 12 Ultimate, AutoHDR, and DirectStorage.
AMD RDNA™ 3 Architecture with Hardware Raytracing
The AMD RDNA™ 3 architecture features industry-advancing chiplet technology to deliver next-generation performance, visuals, and power efficiency. Discover new levels of performance with advanced AMD RDNA™ 3 compute units, featuring redesigned raytracing accelerators for incredible performance while improving image quality.
AMD FreeSync™ Technology
Take full advantage of the AMD Radeon™ RX 7000 Series graphics cards by pairing with a certified AMD FreeSync™ technology-enabled monitor to enable an exceptional stutter and tear-free gaming experience with high refresh rates, low latency, and stunning HDR.
Radeon™ Anti-Lag
Less lag equals more wins. Radeon Anti-Lag reduces latency, providing ultra-fast response time giving you a dynamic edge over your competition.
Radeon™ Boost
Radeon Boost delivers extra performance and improves game smoothness when fast on-screen character motion is detected via user input.
AMD FidelityFX™ Super Resolution 3 technology
AMD FidelityFX™ Super Resolution 3 (AMD FSR 3) is the synergy of next-level AMD temporal upscaling technology and AMD Fluid Motion Frames interpolation technology designed to deliver massive performance boosts with incredible image quality in supported games.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Processor boost clock speed (Gaming mode) | 2213 MHz |
Processor boost clock speed (OC mode) | 2520 MHz |
Processor boost clock speed | 2430 MHz |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
OpenGL version | 4.6 |
DirectX version | 12.0 |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Blue |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | Hellhound |
Weight & dimensions | |
---|---|
Depth | 147 mm |
Height | 50 mm |
Width | 332 mm |
The ASUS Dual GeForce® GTX 1650 OC Edition 4GB GDDR6 EVO rocks high refresh rates in high definition
2x Fans. 2x Fun.
Dual graphics cards are all about maximum efficiency. The recipe is simple; strip off features that don't affect performance and mix in two powerful dust resistant fans with PCB components that are mounted utilizing an automated manufacturing process. The result is a machine tuned purely for lasting performance, making the ASUS Dual GeForce® GTX 1650 a solid introduction to the latest generation of graphics performance.
COOLING
IP5X Dust Resistance
Keep it clean
Dust is enemy number one for fans. It’s easy to clean the blades, but taking the fan apart to remove dust that has made its way inside is not a simple task. Passing the IP5X certification means the housing is safe from nasty particulates, so you'll never need that deep clean.
ENGINEERING
Auto-Extreme Technology
Precision automated manufacturing
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
Stainless Steel Bracket
Steel yourself
The mounting bracket of the Dual GeForce GTX 1650 has been beefed up with 304 Stainless Steel that is harder and more resistant to corrosion.
SOFTWARE
GPU TWEAK III
Monitor, tweak, and tune
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
EXPERIENCE
144-hour Validation Program
"Extensive" may be an understatement
A 144-hour validation program puts cards through a series of stringent tests to ensure compatibility with the latest games.
NVIDIA® G-SYNC®
Smooth operator
This graphics card supports NVIDIA® G-SYNC® display technology for a super-smooth variable refresh rate experience. Enjoy AAA games without the nuisance of screen tearing or stuttering.
Free 1 Month of Adobe Creative Cloud
Get complimentary membership with the purchase of selected ASUS products.*
* Terms and conditions apply. For more details, please read the full terms and published on the event page.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 3 |
Processor boost clock speed (OC mode) | 1785 MHz |
Processor boost clock speed | 1755 MHz |
CUDA cores | 896 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce GTX 1650 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 12 GB/s |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 4 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.0b |
DVI-D ports quantity | 1 |
DisplayPorts quantity | 1 |
HDMI ports quantity | 1 |
Interface type | PCI Express 3.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
HDCP | Yes |
HDCP version | 2.2 |
OpenGL version | 4.6 |
Design | |
---|---|
Product colour | Black, Silver |
Number of slots | 2 |
Number of fans | 2 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 6-pin |
Minimum system power supply | 300 W |
General | |
---|---|
Product Family | Dual |
Weight & dimensions | |
---|---|
Depth | 121 mm |
Height | 40 mm |
Width | 212 mm |
Weight | 421 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 725 g |
Package height | 55 mm |
Package depth | 218 mm |
Package width | 300 mm |
Hellhound Series: Unleash the Power
Introducing the Hellhound models for the 7800 XT and 7700 XT series - where raw power meets sleek design. Tailored for the gaming elite, the Hellhound cards come equipped with an advanced cooling system and high-performance components, ensuring that gamers can dive deep into intense gaming sessions without a hitch.
Engineered for Uncompromising Performance and Durability
The PowerColor 7800 XT Hellhound is meticulously crafted for durability and performance. Its metal-reinforced backplate adds a layer of protection and rigidity, while the Dual BIOS feature offers seamless adaptability between performance modes. Built on a high-quality 14-layer PCB, the card promises enhanced signal quality and longevity.
High Quality Japanese Dual Ball Bearings
Dual ball bearings reduce rotational friction, providing excellent heat dissipation and effectively doubling the expected lifetime of the fans.
Intelligent Fan Controller
Utilizing temperature detection from a smart chip, fans will start running when the GPU reaches 60℃ and shut down below 50℃. Efficient cooling, fan-noise reduction, and extended product lifetime are all benefits of a more accurate temperature monitoring.
Unprecedented Ring-fan Blade Design
The newest 9-blade design of our fans generate better airflow and air pressure under the same noise level, improving cooling performance to reduce GPU temperatures by more than 3℃ compared to previous generations.
GPU Direct-Contact Copper Plate
We have increased the copper plate area to provide direct contact with the GPU while covering VRAM to increase the heat transfer threshold to the max.
Vertical Fin Heatsink
A large heatsink with vertical fins spaced closely is mounted on PCB and offers better heat-spread area and radiation, allowing airflow to disperse heat efficiently.
Turbulence Reducing Fan Rotation
The middle fan spins in the reverse way so as to reduce the air turbulence between neighboring fans when drawing in cool air. The mechanism therefore maximizes the air flow and pressure when less turbulence occurs to offset, further to lower the noise level without sacrificing the cooling efficiency.
Optimum Heatpipe Arrangement
A set of 5 x 6φ nickel-plated copper heatpipes align closely above the PCB to more quickly and effectively transfer heat from the GPU and VRAM to the cooling array.
Car-Grade Power Module DrMOS with iMON Real Time Digital Monitoring
Hellhound adopts a 9+2+1 phase VRM design with DrMOS to power the GPU as well as an additional 2+1 phase specifically designated for the VRAM. New IMON technology monitors and reports the electric current and power consumption on each individual phase. By balancing the workload, the Hellhound ensures unparalleled stability and thermal protection during overclocking.
In addition, high quality car-grade polymer capacitors features long-lasting durability and high conductivity lowers power loss during transmission.
High Quality PCB Design
A premium 14-layer high TG PCB Board -including a 2 oz power layer- is utilized in the Hellhound RX 7800 XT; a PCB such designed decreases signal loss during transmission: important especially for higher-end GPUs with increased demands for higher currents and stability.
Metal Reinforced Backplate
The metal backplate strengthens and protects the internal components from PCB bend, and a cut-out design on the back plate allows exhaust heat to properly flow through for heat-dissipation efficiency.
Brand New Amethyst LED Color
Hellhound of this generation comes with a brand new amethyst purple LED lighting while retaining the previous ice blue. Gamers are able to choose the color they want by flipping the switch on side of the card.
Ice blue shows coolness and elegance while amethyst represents mystery and charm.
Dual BIOS Mode
Hellhound RX 7800 XT features Dual BIOS built-in and a switch for easy swapping.
-OC BIOS: A boosted mode that increases fan RPM to keep your card operating at a lower temperature to drive higher performance.
-Silent BIOS: Focused on lower noise and fan longevity, a milder fan speed, trading fan speed and noise for moderate, but still controlled, temperatures while maintaining performance.
GAME.
STREAM.
ADVANCE.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
GAME
The AMD Radeon™ RX 7800 XT graphics cards set a new level of performance for gamers. Featuring up to 16GB of GDDR6 memory, unified AMD RDNA™ 3 compute units, and next-generation features to enable ultra-fast, ultra-smooth gaming performance at 1440p, and the flexibility to experience ultra-detailed graphics at 4K. Immerse yourself even further with the AMD Radiance Display™ Engine and DisplayPort™ 2.1 to experience up to 68 billion colors for video playback and support for up to 8K.
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
ADVANCE
Combine AMD Radeon™ RX 7700 XT and 7800 XT graphics cards with AMD Ryzen™ processors to activate AMD smart technologies. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon™ RX 7000 Series graphics cards with the AMD Software: Adrenalin Edition™ application, featuring bulletproof drivers, for the best PC gaming experiences.
UPSIZE PERFORMANCE.
MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Optimized for Windows 11
AMD Radeon™ RX 7000 Series Graphics power the ultimate Windows 11 gaming experience with optimized support for DirectX® 12 Ultimate, AutoHDR, and DirectStorage.
AMD RDNA™ 3 Architecture with Hardware Raytracing
The AMD RDNA™ 3 architecture features industry-advancing chiplet technology to deliver next-generation performance, visuals, and power efficiency. Discover new levels of performance with advanced AMD RDNA™ 3 compute units, featuring redesigned raytracing accelerators for incredible performance while improving image quality.
AMD FreeSync™ Technology
Take full advantage of the AMD Radeon™ RX 7000 Series graphics cards by pairing with a certified AMD FreeSync™ technology-enabled monitor to enable an exceptional stutter and tear-free gaming experience with high refresh rates, low latency, and stunning HDR.
Radeon™ Anti-Lag
Less lag equals more wins. Radeon Anti-Lag reduces latency, providing ultra-fast response time giving you a dynamic edge over your competition.
Radeon™ Boost
Radeon Boost delivers extra performance and improves game smoothness when fast on-screen character motion is detected via user input.
AMD FidelityFX™ Super Resolution 3 technology
AMD FidelityFX™ Super Resolution 3 (AMD FSR 3) is the synergy of next-level AMD temporal upscaling technology and AMD Fluid Motion Frames interpolation technology designed to deliver massive performance boosts with incredible image quality in supported games.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Processor boost clock speed (Gaming mode) | 2213 MHz |
Processor boost clock speed (OC mode) | 2520 MHz |
Processor boost clock speed | 2430 MHz |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
OpenGL version | 4.6 |
DirectX version | 12.0 |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Blue |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | Hellhound |
Weight & dimensions | |
---|---|
Depth | 147 mm |
Height | 50 mm |
Width | 332 mm |
PERFORMANCE TO RULE YOUR GAME
GAME. STREAM. ADVANCE.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
BUILT FOR THE GAMER
SPEEDSTER SERIES
The Speedster series exemplifies a modern aerodynamic style through a clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
AIRFLOW AND ASTHETICS
With each iteration of the XFX Qick series, we have simplified the design while improving performance. Our vented Aluminum backplate design ensures improved heat dissipation over traditional solid backplates.
XFX DUAL BIOS READY
We know enthusiast like options, so for the XFX QICK319 7800 XT graphics cards, we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update or flash.
EXTREME STABILITY AND OVERCLOCKING
With a 14-phase power design, and a dedicated 8-phases for GPU GFX Core, the QICK 319 7800 XT provides you with stable gameplay and gives better power distribution across the VRMs. This allows the GPU to operate cooler at baseline but also has tremendous room to overclock thanks to XFX's increased power delivery BIOS.
HIGH EFFICIENCY 13-BLADE FANS - QUIETER & LONGER LIFESPAN
The QICK 319 7800 XT GPUs utilize 13-blade structure fans that provide better endurance and efficiency over other designs. Reducing friction and heat these, fans operate quieter and have increased lifespan.
BREAKTHROUGH PERFORMANCE
Breakthrough new levels of performance with 16GB of GDDR6 memory and blazing-fast clock speeds to deliver an incredible experience at 1440p and beyond. Radeon™ RX 7000 Series graphics feature advanced AMD RDNA™ 3 compute units, with 2nd generation raytracing accelerators and new AI accelerators to deliver incredible performance while maximizing graphical fidelity.
WORLD’S FIRST CHIPLET DESIGNED GAMING GPUS
Featuring ultra-fast 2nd generation AMD Infinity Cache™ technology connected through an ultra-high bandwidth chiplet interconnect. • 28.1 billion Transistors
BREATHTAKING VISUALS
A pixel-perfect experience starts with Radeon™ RX 7800 XT Series graphics cards. Immerse yourself in your favorite visual vistas with stunning image clarity and up to 68 billion colors at up to 8K 165Hz. The Radeon™ RX 7800 XT Series delivers a jaw-dropping visual experience you need to see to believe.
AMD RADIANCE DISPLAY™ ENGINE
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz. • DisplayPort™ 2.1 • 12-Bit HDR up to 68 billion Colors
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders4. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression5 featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
AMD FIDELITYFX™
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
AMD INFINITY CACHE
A revolutionary new memory level in AMD RDNA™ 3 architecture. 64 MB of AMD Infinity Cache enables high bandwidth performance of up to 2709 GB/s Effective Memory Bandwidth
AMD SMART ACCESS MEMORY
Get more performance in select titles through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCIe® 4.0
HIGH PERFORMANCE 1440P GAMING
With up to 60 enhanced compute units delivering powerhouse performance, even 8K gaming is now possible at smooth framerates thanks to FSR.
GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 16GB of advanced GDDR6 memory with a 256-bit interface , enabling 1440p performance in today’s most demanding games.
PCI® EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput of 16 GT/s which enables two times the bandwidth compared to PCIe® 3.0.
500 MILLION GAMERS PLAY ON AMD RADEON
AMD Power most of todays newest consoles but also more Gaming PCs and Consoles are powered by AMD*. It's obvious what is the real choice when it comes to high performance graphics at a great value.
AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
XFX 3 YEAR WARRANTY
Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
Processor | |
---|---|
Stream processors | 3840 |
Ray accelerators | 60 |
Infinity cache | 64 MB |
Processor boost clock speed (Gaming mode) | 2124 MHz |
Processor boost clock speed | 2430 MHz |
Processor frequency | 1295 MHz |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 2708 GB/s |
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Video formats supported | H.264, H.265, HEVC/H.265 |
AMD FreeSync | Yes |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
Technical details | |
---|---|
Sustainability certificates | RoHS |
Sustainability compliance | Yes |
Weight & dimensions | |
---|---|
Depth | 335 mm |
Height | 130 mm |
Width | 52 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.68 kg |
Package height | 125 mm |
Package depth | 235 mm |
Package width | 445 mm |
BUILT FOR THE GAMER
SPEEDSTER SERIES
The Speedster series exemplifies a modern aerodynamic style through a clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
AIRFLOW AND ASTHETICS
With each iteration of the XFX Merc series, we have simplified the design while improving performance. This newest iteration introduces our all-new ridged backplate design which increases the overall surface area by 33%, the results are increased in heat dissipation when paired with thermal pads.
XFX GHOST THERMAL
Our new design features a straight-through airflow venting to significantly improve cooling and compliments the open design of the Ghost Thermal floating shroud design along with numerous other cooling features.
VAPOR CHAMBER
The XFX MERC 319 7800 XT uses a vapor chamber design, a more efficient method for heat dissipation than traditional cold plates alone. The vapor chamber can quickly quickly and efficiently transfer heat from the GPU and VRAM to the heat pipes, and then into the heatsink assembly.
XFX DUAL BIOS READY
We know enthusiast like options, so for the XFX MERC 319 7800 XT graphics cards, we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update or flash.
EXTREME STABILITY AND OVERCLOCKING
With a 14-phase power design, and a dedicated 9-phases for GPU GFX Core, the QICK 319 7800 XT provides you with stable gameplay and gives better power distribution across the VRMs. This allows the GPU to operate cooler at baseline but also has tremendous room to overclock thanks to XFX's increased power delivery BIOS.
HIGH EFFICIENCY 13-BLADE FANS - QUIETER & LONGER LIFESPAN
The MERC 319 7800 XT GPUs utilize 13-blade structure fans that provide better endurance and efficiency over other designs. Reducing friction and heat these, fans operate quieter and have increased lifespan.
BREAKTHROUGH PERFORMANCE
Breakthrough new levels of performance with 16GB of GDDR6 memory and blazing-fast clock speeds to deliver an incredible experience at 1440p and beyond. Radeon™ RX 7000 Series graphics feature advanced AMD RDNA™ 3 compute units, with 2nd generation raytracing accelerators and new AI accelerators to deliver incredible performance while maximizing graphical fidelity.
WORLD’S FIRST CHIPLET DESIGNED GAMING GPUS
Featuring ultra-fast 2nd generation AMD Infinity Cache™ technology connected through an ultra-high bandwidth chiplet interconnect. • 28.1 billion Transistors
BREATHTAKING VISUALS
A pixel-perfect experience starts with Radeon™ RX 7800 XT Series graphics cards. Immerse yourself in your favorite visual vistas with stunning image clarity and up to 68 billion colors at up to 8K 165Hz. The Radeon™ RX 7800 XT Series delivers a jaw-dropping visual experience you need to see to believe.
AMD RADIANCE DISPLAY™ ENGINE
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz. • DisplayPort™ 2.1 • 12-Bit HDR up to 68 billion Colors
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders4. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression5 featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
AMD FIDELITYFX™
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
AMD INFINITY CACHE
A revolutionary new memory level in AMD RDNA™ 3 architecture. 64 MB of AMD Infinity Cache enables high bandwidth performance of up to 2709 GB/s Effective Memory Bandwidth
AMD SMART ACCESS MEMORY
Get more performance in select titles through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCIe® 4.0
HIGH PERFORMANCE 1440P GAMING
With up to 60 enhanced compute units delivering powerhouse performance, even 8K gaming is now possible at smooth framerates thanks to FSR.
GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 16GB of advanced GDDR6 memory with a 256-bit interface , enabling 1440p performance in today’s most demanding games.
PCI® EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput of 16 GT/s which enables two times the bandwidth compared to PCIe® 3.0.
500 MILLION GAMERS PLAY ON AMD RADEON
AMD Power most of todays newest consoles but also more Gaming PCs and Consoles are powered by AMD. It's obvious what is the real choice when it comes to high performance graphics at a great value.
AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
XFX 3 YEAR WARRANTY
Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
Processor | |
---|---|
Stream processors | 3840 |
Processor boost clock speed (Gaming mode) | 2254 MHz |
Processor boost clock speed | 2565 MHz |
Processor frequency | 1624 MHz |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 2708 GB/s |
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Video formats supported | H.264, H.265, HEVC/H.265 |
AMD FreeSync | Yes |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Stainless steel |
Number of slots | 2.75 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
Technical details | |
---|---|
Sustainability certificates | RoHS |
Sustainability compliance | Yes |
Weight & dimensions | |
---|---|
Depth | 326 mm |
Height | 126 mm |
Width | 58 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2 kg |
Package height | 125 mm |
Package depth | 235 mm |
Package width | 445 mm |
PERFORMANCE TO RULE YOUR GAME
GAME. STREAM. ADVANCE.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
SPEEDSTER SERIES
The Speedster series exemplifies a modern aerodynamic style through a clean and elegant design. It is a thoughtful design with the sole purpose of maximizing airflow to improve cooling and performance.
AIRFLOW AND ASTHETICS
With each iteration of the XFX Qick series, we have simplified the design while improving performance. Our vented Aluminum backplate design ensures improved heat dissipation over traditional solid backplates.
XFX DUAL BIOS READY
We know enthusiast like options, so for the XFX QICK319 7700 XT graphics cards, we are offering dual BIOS. Giving a backup BIOS in the case of a failed BIOS update or flash.
EXTREME STABILITY AND OVERCLOCKING
With a 14-phase power design, and a dedicated 8-phases for GPU GFX Core, the QICK 319 7800 XT provides you with stable gameplay and gives better power distribution across the VRMs. This allows the GPU to operate cooler at baseline but also has tremendous room to overclock thanks to XFX's increased power delivery BIOS.
HIGH EFFICIENCY 13 BLADE FANS - QUIETER & LONGER LIFESPAN
The MERC 319 7700 XT GPUs utilize 13-blade structure fans that provide better endurance and efficiency over other designs. Reducing friction and heat these, fans operate quieter and have increased lifespan.
BREAKTHROUGH PERFORMANCE
Breakthrough new levels of performance with 12GB of GDDR6 memory and blazing-fast clock speeds to deliver an incredible experience at 1440p and beyond. Radeon™ RX 7000 Series graphics feature advanced AMD RDNA™ 3 compute units, with 2nd generation raytracing accelerators and new AI accelerators to deliver incredible performance while maximizing graphical fidelity.
WORLD’S FIRST CHIPLET DESIGNED GAMING GPUS
Featuring ultra-fast 2nd generation AMD Infinity Cache™ technology connected through an ultra-high bandwidth chiplet interconnect. • 28.1 billion Transistors
BREATHTAKING VISUALS
A pixel-perfect experience starts with Radeon™ RX 7700 XT Series graphics cards. Immerse yourself in your favorite visual vistas with stunning image clarity and up to 68 billion colors at up to 8K 165Hz. The Radeon™ RX 7700 XT Series delivers a jaw-dropping visual experience you need to see to believe.
AMD RADIANCE DISPLAY™ ENGINE
The AMD Radiance Display™ Engine features 12-bit HDR and full coverage of the REC2020 color space for incredible color accuracy. With support for DisplayPort™ 2.1, experience breathtaking visuals with up to 68 Billion colors at up to 8K 165Hz. • DisplayPort™ 2.1 • 12-Bit HDR up to 68 billion Colors
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders4. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression5 featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
AMD FIDELITYFX™
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games. AMD Radeon™ Super Resolution (RSR)2 leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
AMD INFINITY CACHE
A revolutionary new memory level in AMD RDNA™ 3 architecture. 48 MB of AMD Infinity Cache enables high bandwidth performance of up to 1995 GB/s Effective Memory Bandwidth
GDDR6 MEMORY FOR ADVANCED GAMING
Equipped with 12GB of advanced GDDR6 memory with a 192-bit interface , enabling 1440p performance in today’s most demanding games.
AMD SMART ACCESS MEMORY
Get more performance in select titles through new levels of communication between AMD Ryzen™ desktop processors and AMD Radeon™ graphics cards over PCIe® 4.0
PCI® EXPRESS 4.0 SUPPORT
The AMD Radeon™ RX 7000 Series graphics cards feature PCIe® 4.0, with a throughput of 16 GT/s which enables two times the bandwidth compared to PCIe® 3.0.
HIGH PERFORMANCE 1440P GAMING
With up to 54 enhanced compute units delivering powerhouse performance, even 8K gaming is now possible at smooth framerates thanks to FSR.
500 MILLION GAMERS PLAY ON AMD RADEON
AMD Power most of todays newest consoles but also more Gaming PCs and Consoles are powered by AMD*. It's obvious what is the real choice when it comes to high performance graphics at a great value.
AMD RADEON™ IS WINDOWS 11 READY
Windows® 11 is created for the ultimate PC gaming, featuring superior graphics, amazing speed, and an incredible selection of games. Windows 11 includes gaming features like DirectX® 12
XFX 3 YEAR WARRANTY
Even though we trust that our high quality products will continue working at peak performance well beyond the use of it, we want to put our word behind that promise. That is why we offer our 3 Year Warranty with this series of graphics cards. This means that your product is protected by a 3 year limited hardware warranty on manufacturing defects of anything on the card.
Processor | |
---|---|
Stream processors | 3456 |
Processor boost clock speed (Gaming mode) | 2276 MHz |
Processor boost clock speed | 2599 MHz |
Processor frequency | 1785 MHz |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 1995 GB/s |
Data transfer rate | 18 Gbit/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Video formats supported | H.264, H.265, HEVC/H.265 |
AMD FreeSync | Yes |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
Technical details | |
---|---|
Sustainability certificates | RoHS |
Sustainability compliance | Yes |
Weight & dimensions | |
---|---|
Depth | 335 mm |
Height | 130 mm |
Width | 52 mm |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.68 kg |
Package height | 125 mm |
Package depth | 235 mm |
Package width | 445 mm |
Digital Power Design
SAPPHIRE PURE AMD Radeon™ RX 7000 Series are designed with digital power which provides accurate power control and excellent power efficiency
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Graphics Card Supporter
Bundled with a graphics card supporter to keep the graphics card in place on the PCIe Slot.
Red LED SAPPHIRE Logo
Finishing off the beautiful look of these cards are the chic grey accents etched onto the exterior along with a Red LED SAPPHIRE logo with a hardware switch to turn the red lighting on and off at will.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Ray accelerators | 60 |
Lithography | 5 nm |
Infinity cache | 64 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2475 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
AMD FreeSync | Yes |
Dual Link DVI | No |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Illumination colour | Red |
Number of slots | 2.5 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling technology | Sapphire Tri-X |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Power consumption (max) | 270 W |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | PURE |
Weight & dimensions | |
---|---|
Depth | 320 mm |
Height | 52.6 mm |
Width | 128.8 mm |
Packaging data | |
---|---|
Package type | Box |
Polychrome SYNC
Create your own unique colorful light effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
LED On/Off Switch
On or Off? Switch as You Want.
You can switch not only the built-in ARGB LEDs but also the ARGB LEDs equipping with the connected strips/devices at once.
Triple Fan Design
Triple fan design helps to optimize system cooling to reduce the operating temperature.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Reinforced Metal Frame
Be solid. No sag.
Enhances the structure to prevent the PCB from being bent.
Striped Axial Fan
Designed For Enhanced Airflow.
ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Air Deflecting Fin
Guide Airflow to Go Through Regularly & Quickly.
Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Nicked Plated Total Copper Base
Optimize GPU and VRAM thermal transfer.
The large nickel-plated total copper base helps to optimize the thermal transfer for both GPU and VRAM effectively.
High-density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.
Premium 90A Power Choke
Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro and Easy-to-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
AMD Eyefinity Technology
AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games.
AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Ray accelerators | 60 |
Infinity cache | 64 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2520 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 2.8 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 800 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 304 mm |
Height | 131 mm |
Width | 56 mm |
Weight | 1.24 kg |
Packaging data | |
---|---|
Package type | Box |
Reverse Spin
The center fan spins reversely to lower turbulence and enhance air dispersion through the heatsink.
Phantom Gaming 3X Cooling System
For Cool And Silent.
Crafted for the best balance between the thermal efficiency and silence by all the details.
Striped Ring Fan
Designed For Enhanced Airflow
ASRock’s all new Striped Ring Fan get more lateral intake and to provide better airflow through the cooling array.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Air Deflecting Fin
Guide Airflow To Go Through Regularly & Quickly.
Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
Ultra-Fit Heatpipe
Consolidated To Maximize The Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Nickel-Plated Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
High-Density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Polychrome SYNC
Create Your Own Unique Colorful Light Effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
LED On/Off Switch
On Or Off? Switch As You Want.
You can switch not only the built-in ARGB LEDs but also the ARGB LEDs equipping with the connected strips/devices at once.
Reinforced Metal Frame
Be Solid. No Sag.
Enhances the structure to prevent the PCB from being bent.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.
Premium 90A Power Choke
Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro And Easy-To-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
AMD Eyefinity Technology
AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
GAME
The AMD Radeon™ RX 7700 XT and 7800 XT graphics cards set a new level of performance for gamers. Featuring up to 16GB of GDDR6 memory, unified AMD RDNA™ 3 compute units, and next-generation features to enable ultra-fast, ultra-smooth gaming performance at 1440p, and the flexibility to experience ultra-detailed graphics at 4K. Immerse yourself even further with the AMD Radiance Display™ Engine and DisplayPort™ 2.1 to experience up to 68 billion colors for video playback and support for up to 8K.
STREAM
Get ready for next-generation, high-fidelity streaming using your favorite software, OBS Studio, with the new hardware AV1 encoders. With improved encoding performance and enhanced visual quality when streaming, the Radeon™ RX 7700 XT and 7800 XT graphics cards are the ultimate plug-and-play solution for gamers and streamers. Enable AMD Noise Suppression featuring AI to eliminate ambient noise and communicate clearly with your audience or teammates.
ADVANCE
Combine AMD Radeon™ RX 7700 XT and 7800 XT graphics cards with AMD Ryzen™ processors to activate AMD smart technologies. You can unleash outstanding performance to give you an edge in the game. Advance your AMD Radeon™ RX 7000 Series graphics cards with the AMD Software: Adrenalin Edition™ application, featuring bulletproof drivers, for the best PC gaming experiences.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games.
AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 60 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2599 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Multi |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling technology | Phantom Gaming 3X Cooling |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | Phantom Gaming |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 328 mm |
Height | 140 mm |
Width | 52 mm |
Weight | 1.45 kg |
Packaging data | |
---|---|
Package type | Box |
Digital Power Design
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7800 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7800 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Ray accelerators | 60 |
Infinity cache | 64 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2124 MHz |
Processor boost clock speed | 2430 MHz |
Processor frequency | 2124 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
DirectX version | 12 Ultimate |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 2 fan(s) |
Cooling technology | Sapphire Dual-X |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 266 W |
Supplementary power connectors | 2x 8-pin |
Power consumption (max) | 266 W |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10, Windows 11 x64 |
General | |
---|---|
Product Family | PULSE |
Packaging content | |
---|---|
Quick installation guide | Yes |
Technical details | |
---|---|
Warranty period | 3 year(s) |
Weight & dimensions | |
---|---|
Depth | 128.8 mm |
Height | 52.6 mm |
Width | 280 mm |
Software BIOS Switch
Switch from performance mode to silent mode or back using our TriXX software for a quick and easy switch between your dual BIOS modes.
Backplate
Provides rigidity and helps cool your card by increasing heat dissipation.
WAVE Fin Design & V-Shape Fin Design for GPU cooling
The WAVE Fin Design reduces friction when the wind goes into the fin module resulting in a reduction of the wind cut noise.
The V-shape fin design on top of the GPU accelerates and centralizes the air flow around the GPU to dissipate heat efficiently.
Cold Rolled Steel Frame
Experience a superior and beautifully crafted frame on the NITRO+ AMD Radeon™ RX 7800 XT Graphics Card with a Cold Rolled Steel Frame that fortifies the shroud structure and durability while encasing the sides of the PCB for a strong encasement alongside the All Metal Backplate.
Digital Power Design
SAPPHIRE NITRO+ AMD Radeon™ RX 7000 Series are designed with digital power which provides accurate power control and excellent power efficiency
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Dedicated VRM Cooling
Dedicated VRM cooling module to create optimal heat dissipation for peak airflow and cooling performance.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7800 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Assistive System Fan Control
When the temperature of the GPU increases, the graphics card fans speed up accordingly. To further help with cooling and heat dissipation, the Assistive System Fan Control feature in SAPPHIRE’s TriXX software controls the speed of a system fan to automatically increase at the same time as the graphics card fans, this assists in expelling the heated air from the entire system faster.
Dual BIOS
Choose between Primary BIOS mode or Secondary mode to enhance your gaming experience.
Graphics Card Supporter
Bundled with a graphics card supporter to keep the graphics card in place on the PCIe Slot.
ARGB Light Bar
With tasteful shroud design augmented by ARGB LEDs, you can change the colors of the LED, for a customized design. This can be controlled via TriXX software. Choose from different modes including Fan Speed Mode, PCB Temperature Mode or the colourful rainbow mode or turn off the LEDs.
External ARGB Control Sync
Enable the external synchronization of RGB LEDs between the graphics card and the motherboard using the 3-pin header in the tail. Gamers can then choose if the graphics card performs the RGB LED effects independently or if the motherboard acquires control.
Fan Quick Connect
If there’s a fan problem, you don’t have to return the entire card. SAPPHIRE or our channel partners will send out a replacement fan directly to you! That means they’re easy to remove, clean and replace, with just one screw holding them securely in place.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Ray accelerators | 60 |
Infinity cache | 64 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2254 MHz |
Processor boost clock speed | 2565 MHz |
Processor frequency | 2254 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 19.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
DirectX version | 12 Ultimate |
Design | |
---|---|
Illumination | Yes |
Number of slots | 3 |
Number of fans | 3 fan(s) |
Cooling technology | Sapphire Tri-X |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 288 W |
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64, Windows 11 Enterprise x64, Windows 11 x64 |
General | |
---|---|
Product Family | NITRO+ |
Packaging content | |
---|---|
Quick installation guide | Yes |
Technical details | |
---|---|
Warranty period | 3 year(s) |
Weight & dimensions | |
---|---|
Depth | 134.8 mm |
Height | 61.6 mm |
Width | 320 mm |
Polychrome SYNC
Create your own unique colorful light effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
LED On/Off Switch
On or Off? Switch as You Want.
You can switch not only the built-in ARGB LEDs but also the ARGB LEDs equipping with the connected strips/devices at once.
Triple Fan Design
Triple fan design helps to optimize system cooling to reduce the operating temperature.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Reinforced Metal Frame
Be solid. No sag.
Enhances the structure to prevent the PCB from being bent.
Striped Axial Fan
Designed For Enhanced Airflow.
ASRock’s custom Striped Axial Fan delivers enhanced airflow to optimize cooling from not only the stripe structure on each fan blade but also the polishing surface on the bottom side.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Air Deflecting Fin
Guide Airflow to Go Through Regularly & Quickly.
Guide the airflow to go more regularly and quickly to enhance the cooling efficiency by the V-shaped cutting fins and the V-shaped air vents.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Nicked Plated Total Copper Base
Optimize GPU and VRAM thermal transfer.
The large nickel-plated total copper base helps to optimize the thermal transfer for both GPU and VRAM effectively.
High-density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.
Premium 90A Power Choke
Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro and Easy-to-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
AMD Eyefinity Technology
AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games.
AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 48 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2599 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 2.8 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 750 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 304 mm |
Height | 131 mm |
Width | 56 mm |
Weight | 1.24 kg |
Packaging data | |
---|---|
Package type | Box |
Dual Fan Design
Two fans that provide strong cooling performance and make your gaming rig stay cool. It’s optimized for delivering excellent gaming experience with stylish and streamlined design.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
Striped Ring Fan
Designed For Enhanced Airflow
ASRock’s all new Striped Ring Fan get more lateral intake and to provide better airflow through the cooling array.
LED Indicators
More Decoration. More Beauty.
LED indicator embellished the graphics card to make it more beautiful.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Ultra-fit Heatpipe
Consolidated to Maximize the Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
High-density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
Dr. MOS
Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Intelligently delivering higher current and driving up to 50A continuous current for each phase, thus providing improved thermal result and superior performance.
Premium 90A Power Choke
Compared to traditional chokes, ASRock’s premium 90A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
ASRock Tweak 2.0
Pro and Easy-to-Use Tuning Utility.
Provides the smart fan speed control and instant performance tweaking.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
PCI® Express 4.0 Support
This graphics card features PCI® Express 4.0 support, with a throughput of 16 GT/s and enables two times the bandwidth compared to PCI® Express 3.0. Get ready for the next generation of PC gaming.
AMD Eyefinity Technology
AMD Eyefinity technology expands the traditional limits of desktop computing by multiplying your screen area. With multiple monitors, games become more immersive, workstations become more useful and you become more productive.
Experience incredible performance, visuals, and efficiency when gaming and streaming with the AMD Radeon™ RX 7700 XT and 7800 XT graphics cards, powered by the AMD RDNA™ 3 architecture. Immerse yourself in next-generation desktop experiences on some of the most advanced high refresh rate displays with up to 16GB of GDDR6 memory, new frame generation technologies, advanced raytracing, AI accelerators, AV1 encoding, and support for the latest DisplayPort™ 2.1 technology. The Radeon™ RX 7700 XT and 7800 XT delivers an incredible high refresh 1440p gaming & streaming experience, with additional video memory to step into 4K.
UPSIZE PERFORMANCE. MAXIMIZE FIDELITY
AMD FidelityFX™ Super Resolution technology takes upscaling technology to the next level. Providing incredible image quality while boosting framerates in supported games.
AMD Radeon™ Super Resolution (RSR) leverages FSR technology on the driver level, giving you upscaled performance benefits across thousands of games.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 48 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed | 2854 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | White |
Number of fans | 2 fan(s) |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | Challenger |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 266 mm |
Height | 130 mm |
Width | 51 mm |
Weight | 985 g |
Packaging data | |
---|---|
Package type | Box |
AMD RDNA™ 3 Architecture
- 12GB of GDDR6 memory
- AMD Radiance Display™ Engine
- DisplayPort™ 2.1
- AMD FidelityFX™ Super Resolution
- AMD Radeon Super Resolution
- 1440P and Beyond
Digital Power Design
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7700 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 48 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2171 MHz |
Processor boost clock speed | 2544 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 18 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
DirectX version | 12 Ultimate |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 2 fan(s) |
Cooling technology | Sapphire Dual-X |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 230 W |
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Minimum RAM | 8192 MB |
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | PULSE |
Weight & dimensions | |
---|---|
Depth | 52.6 mm |
Height | 128.8 mm |
Width | 280 mm |
FLYIN’ TUF
The AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond,
and backed with an arsenal of rugged reinforcements to cover your six.
Lock, load, and dominate with the TUF Gaming Radeon™ RX 7700 XT.
AXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 24% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
2.96-SLOT DESIGN
Phase That Blaze
A generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7700 XT GPU, allowing it to be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
METAL EXOSKELETON
Suit Up
An aluminum shroud and backplate prevent PCB flex and feature large vents to further increase heat dissipation.
AUTO-EXTREME TECHNOLOGY
RELIABILITY BOOST
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC
Light ‘em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
GRAPHICS CARD HOLDER
Pillar of Support
The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.
GPU Tweak III
Monitor, tweak, and tune
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
QuantumCloud
Profit from GPU power
QuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!
AMD Software
Change the way you game
The latest AMD Software unleashes the full potential of your GPU with day-0 drivers optimized for new game releases and a highly customizable gaming experience.
Pair with a PSU
Use our wattage calculator to estimate how much power you’ll need to fuel your rig and then pick a compatible ROG Thor, ROG Loki, or ROG Strix AURA PSU for ultimate performance.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2425 MHz |
Processor boost clock speed (OC mode) | 2599 MHz |
Processor boost clock speed | 2599 MHz |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Data transfer rate | 18 Gbit/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
HDCP version | 2.3 |
OpenGL version | 4.6 |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Grey |
Illumination | Yes |
Illumination colour | Blue, Green, Red |
Number of slots | 2.96 |
Number of fans | 3 fan(s) |
Cooling technology | ASUS Axial-tech |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | TUF Gaming |
Weight & dimensions | |
---|---|
Depth | 150.9 mm |
Height | 59.2 mm |
Width | 319.8 mm |
Weight | 1.48 kg |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2.2 kg |
Package height | 87 mm |
Package depth | 226 mm |
Package width | 420 mm |
Manual | Yes |
FLYIN’ TUF
The AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond,
and backed with an arsenal of rugged reinforcements to cover your six.
Lock, load, and dominate with the TUF Gaming Radeon™ RX 7800 XT.
AXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 24% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
2.96-SLOT DESIGN
Phase That Blaze
A generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7800 XT GPU, allowing it to be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
METAL EXOSKELETON
Suit Up
An aluminum shroud and backplate prevent PCB flex and feature large vents to further increase heat dissipation.
LOCK, LOAD, AND LET THE PERFORMANCE FLOW
The Radeon™ RX 7800 XT gloriously presented on a backdrop of low noise and rugged durability.
AUTO-EXTREME TECHNOLOGY
RELIABILITY BOOST
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC
Light ‘em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
GRAPHICS CARD HOLDER
Pillar of Support
The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.
GPU Tweak III
Monitor, tweak, and tune
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
QuantumCloud
Profit from GPU power
QuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!
AMD Software
Change the way you game
The latest AMD Software unleashes the full potential of your GPU with day-0 drivers optimized for new game releases and a highly customizable gaming experience.
Free 1 Month of Adobe Creative Cloud
Get complimentary membership with the purchase of selected ASUS products.*
20+ Adobe apps
Industry-leading apps including Photoshop, Illustrator, InDesign, Spark and XD.
Adobe Fonts
Access thousands of fonts right within your Creative Cloud apps.
Behance
Find inspiration in the world’s largest creative community.
Creative Cloud Libraries
Your team can share assets across their apps and devices, so everyone’s in sync.
1TB of cloud storage per user
Extra storage makes it easier for your team to share and manage creative assets.
Processor | |
---|---|
Stream processors | 3840 |
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7800 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 19.5 GB/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
HDCP version | 2.3 |
OpenGL version | 4.6 |
DirectX version | No |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Grey |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 2.96 |
Form factor | Full-Height/Full-Length (FH/FL) |
Number of fans | 3 fan(s) |
Cooling technology | ASUS Axial-tech |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 750 W |
General | |
---|---|
Product Family | TUF Gaming |
Weight & dimensions | |
---|---|
Depth | 319.8 mm |
Height | 59.2 mm |
Width | 150.9 mm |
Weight | 1.48 kg |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2.2 kg |
Package height | 87 mm |
Package depth | 226 mm |
Package width | 420 mm |
AMD RDNA™ 3 Architecture
- 12GB of GDDR6 memory
- AMD Radiance Display™ Engine
- DisplayPort™ 2.1
- AMD FidelityFX™ Super Resolution
- AMD Radeon Super Resolution
- 1440P and Beyond
Digital Power Design
SAPPHIRE PURE AMD Radeon™ RX 7000 Series are designed with digital power which provides accurate power control and excellent power efficiency
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Graphics Card Supporter
Bundled with a graphics card supporter to keep the graphics card in place on the PCIe Slot.
Red LED SAPPHIRE Logo
Finishing off the beautiful look of these cards are the chic grey accents etched onto the exterior along with a Red LED SAPPHIRE logo with a hardware switch to turn the red lighting on and off at will.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 48 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2226 MHz |
Processor boost clock speed | 2584 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 18 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
DirectX version | 12 Ultimate |
Design | |
---|---|
Product colour | White |
Illumination | Yes |
Illumination colour | Red |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling technology | Sapphire Tri-X |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 240 W |
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Minimum RAM | 8192 MB |
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | PURE |
Weight & dimensions | |
---|---|
Depth | 52.6 mm |
Height | 128.8 mm |
Width | 320 mm |
AMD RDNA™ 3 Architecture
- 12GB of GDDR6 memory
- AMD Radiance Display™ Engine
- DisplayPort™ 2.1
- AMD FidelityFX™ Super Resolution
- AMD Radeon Super Resolution
- 1440P and Beyond
Software BIOS Switch
Switch from performance mode to silent mode or back using our TriXX software for a quick and easy switch between your dual BIOS modes.
SAPPHIRE NITRO+ Graphics Cards
Backplate
Provides rigidity and helps cool your card by increasing heat dissipation.
ARGB
Personalize the look of your NITRO + card with its built-in ARGB.
Outputs
Choose from HDMI and DP slots for a maximum of 4 outputs
Cooling
Innovative cooling technologies to ensure optimal performance and airflow.
WAVE Fin Design & V-Shape Fin Design for GPU cooling
The WAVE Fin Design reduces friction when the wind goes into the fin module resulting in a reduction of the wind cut noise.
The V-shape fin design on top of the GPU accelerates and centralizes the air flow around the GPU to dissipate heat efficiently.
Cold Rolled Steel Frame
Experience a superior and beautifully crafted frame on the NITRO+ AMD Radeon™ RX 7700 XT Graphics Card with a Cold Rolled Steel Frame that fortifies the shroud structure and durability while encasing the sides of the PCB for a strong encasement alongside the All Metal Backplate.
Digital Power Design
SAPPHIRE NITRO+ AMD Radeon™ RX 7000 Series are designed with digital power which provides accurate power control and excellent power efficiency
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Dedicated VRM Cooling
Dedicated VRM cooling module to create optimal heat dissipation for peak airflow and cooling performance.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Assistive System Fan Control
When the temperature of the GPU increases, the graphics card fans speed up accordingly. To further help with cooling and heat dissipation, the Assistive System Fan Control feature in SAPPHIRE’s TriXX software controls the speed of a system fan to automatically increase at the same time as the graphics card fans, this assists in expelling the heated air from the entire system faster.
Dual BIOS
Choose between Primary BIOS mode or Secondary mode to enhance your gaming experience.
Graphics Card Supporter
Bundled with a graphics card supporter to keep the graphics card in place on the PCIe Slot.
ARGB Light Bar
With tasteful shroud design augmented by ARGB LEDs, you can change the colors of the LED, for a customized design. This can be controlled via TriXX software. Choose from different modes including Fan Speed Mode, PCB Temperature Mode or the colourful rainbow mode or turn off the LEDs.
External ARGB Control Sync
Enable the external synchronization of RGB LEDs between the graphics card and the motherboard using the 3-pin header in the tail. Gamers can then choose if the graphics card performs the RGB LED effects independently or if the motherboard acquires control.
Fan Quick Connect
If there’s a fan problem, you don’t have to return the entire card. SAPPHIRE or our channel partners will send out a replacement fan directly to you! That means they’re easy to remove, clean and replace, with just one screw holding them securely in place.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
TRI-X COOLING TECHNOLOGY
An innovative mixture of Robust VRM Cooling and independent memory thermal modules work in tandem to remove heat efficiently and effectively across all sections
Tunneled fins increase convection airflow and ensure wind continuously flows through the cooling and fan system
Heat is dissipated by a trio of large efficient fans running anticlockwise to maximize airflow.
Processor | |
---|---|
Stream processors | 3456 |
Parallel processing technology support | Not supported |
Ray accelerators | 54 |
Infinity cache | 48 MB |
Maximum displays per videocard | 4 |
Processor boost clock speed (Gaming mode) | 2276 MHz |
Processor boost clock speed | 2599 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Radeon RX 7700 XT |
Graphics processor family | AMD |
Memory | |
---|---|
Memory bandwidth (max) | 18 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.1 |
DisplayPorts quantity | 2 |
HDMI ports quantity | 2 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
Design | |
---|---|
Product colour | Multicolour |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 3 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling technology | Sapphire Tri-X |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 252 W |
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Minimum RAM | 8192 MB |
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | NITRO+ |
Packaging content | |
---|---|
Quick installation guide | Yes |
Technical details | |
---|---|
Warranty period | 3 year(s) |
Weight & dimensions | |
---|---|
Depth | 61.6 mm |
Height | 134.8 mm |
Width | 320 mm |
The GeForce RTX™ 4060 Ti JetStream fashioned in jet-black with geometric block patterns demonstrates a performance-focused design that remains the essences to achieve any gaming and media application. Its stealthy approach intends to suit users who prefer function over form, or fancy to keep their PCs in dark presence.
Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing.
NVIDIA Reflex
NVIDIA Reflex and GeForce RTX™ 40 Series GPUs deliver the lowest latency and best responsiveness for the ultimate competitive advantage. Built to optimize and measure system latency, Reflex provides faster target acquisition, quicker reaction times, and the best aim precision for competitive game
Ray Tracing
The Ada architecture unleashes the full glory of ray tracing, which simulates how light behaves in the real world. With the power of RTX 40 Series and third-gen RT Cores, you can experience incredibly detailed virtual worlds like never before.
0-dB TECH
Keep Silent while you are experiencing the multimedia application and general workload. The operating fans only occurs while working on heavier loading.
Palit’s new ThunderMaster has thorough upgrade from the previous version. It has more user-friendly interface as well as more personalized settings. With ThunderMaster, you can control your video card from overclock setting, fan speed to LED effect. You can also monitor GPU status with ThunderMaster utility.
NVIDIA G-SYNC®
Get smooth, tear-free gameplay at high refresh rates, plus HDR and more. This is the ultimate gaming display and the go-to equipment for enthusiast gamers.
Processor | |
---|---|
Processor boost clock speed | 2535 MHz |
CUDA cores | 4352 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4060 Ti |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 288 GB/s |
Data transfer rate | 18 Gbit/s |
Memory clock speed | 2310 MHz |
Memory bus | 128 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1a |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA Ansel | Yes |
NVIDIA G-SYNC | Yes |
Virtual Reality (VR) ready | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
Design | |
---|---|
Product colour | Black |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling type | Active |
Power | |
---|---|
Power consumption (typical) | 650 W |
Supplementary power connectors | 1x 8-pin |
Weight & dimensions | |
---|---|
Depth | 249.9 mm |
Height | 114.9 mm |
Width | 49.7 mm |
OC Edition
Great Performance.
Delivers great performance which is more higher than reference cards based on the solid hardware design.
Phantom Gaming 3X Cooling System
For Cool And Silent.
Crafted for the best balance between the thermal efficiency and silence by all the details.
Ultra-Fit Heatpipe
Consolidated To Maximize The Contact.
The heatpipes are consolidated to maximize the contact among each others and also the GPU baseplate for the optimized heat dissipation.
Copper Base
Maximize GPU Contact Area.
With premium copper base heatsink design, the direct contact area to the GPU would be maximized to improve thermal transfer effectively.
High-Density Metal Welding
Improve Heat Dissipation.
Effectively isolate all coverage of the gap between pipe and stacked fins, hence improve heat dissipation effectively.
Nano Thermal Paste
Perfect Thermal Teamwork.
Eliminate the gaps in the contact area to maximize heat transfer and thermal efficiency.
Premium Thermal Pad
Better Heat Transfer.
The premium thermal pad helps to transfer the heat of the components to the heatsink, improving heat dissipation.
Precise Screw Torque
Optimized Mounting Pressure.
ASRock adopts precise screw torque when assembling its graphics cards to optimize the cooler mounting pressure to improve thermal efficiency while avoiding damage to GPU die.
0dB Silent Cooling
Spin For Cooling, Stop For Silence.
The fan spins when the temperature goes high for the optimal cooling, and stops when the temperature goes low for the complete silence.
Polychrome SYNC
Create Your Own Unique Colorful Light Effects.
With the integrated ARGB LEDs, you can create your own unique colorful light effects which can also be switched on and off. It can also be synchronized with your ASRock motherboards that support Polychrome SYNC.
Stylish Metal Backplate
Solid, Fancy, Cool.
Designed to avoid PCB bending. The fancy outlook makes the graphic card more legendary in visual. It also helps to enhance cooling with the premium thermal pads equipped backside.
SPS (Smart Power Stage)
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the GPU with enhanced performance and OC capability.
Premium 100A Power Choke
Compared to traditional chokes, ASRock’s premium 100A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the graphics card.
2oz Copper PCB
Using only carefully selected copper materials for PCB layers, 2oz Copper PCB delivers lower temperature and higher energy efficiency for overclocking.
Matte Black PCB
A new mysterious matte black and copper color scheme to match the prestigious components on ASRock's high-end graphics card.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the graphics card against electrical shorts caused by humidity.
8K Resolution Support
Not only can it handles 4K graphics but also supports the next generation 8K video output for the ultimate visual experience.
Supercharge Your Gaming.
Dive into immersive, high-performance gaming with AI-enhanced XeSS upscaling and full support for DirectX 12 Ultimate.
Experience Immersive High-Performance Gaming.
Intel® Arc™ Control gives gamers options and controls to refine their gaming experience in an intuitive and modern layout. Get seamless driver updates, optimize your favorite games, stream from your home without interruption and more.
Xe Super Sampling (XeSS)
Take your gaming experience to the next level with AI-enhanced upscaling technology, enabling more performance with high image fidelity.
DirectX 12 Ultimate Support
Fully compatible with the latest breakthroughs in graphics technologies, including ray tracing, variable rate shading, mesh shading and sampler feedback - the fundamentals for next-gen gaming.
Unleash Your Creativity.
Experience cutting-edge AI-accelerated content creation.
With industry-first AV1 hardware encode and the advanced Intel® Xe Media Engine, the most comprehensive media capabilities are at your fingertips.
Take Center Stage.
Broadcast seamlessly with advanced streaming technologies enabled by Intel® Arc™ Control software.
Elevate Your Gaming Experience.
Refine your gaming experience with Intel® Arc™ Control in an intuitive and modern layout. Get seamless driver updates and optimize many of your favorite games.
Maximize Your Intel® Platform.
Enhance your creation, gaming and streaming experiences with Intel® Deep Link Technology features by pairing Intel® Core™ processors with Intel® Arc™ graphics.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor frequency | 2200 MHz |
CUDA | No |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | Arc A770 |
Graphics processor family | Intel |
Memory | |
---|---|
Data transfer rate | 17.5 Gbit/s |
Memory bus | 256 bit |
Graphics card memory type | GDDR6 |
Discrete graphics card memory | 16 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 2.0 |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express x16 4.0 |
Performance | |
---|---|
Intel® Xe Matrix Extensions (Intel® XMX) Engines | 512 |
Xe-cores | 32 |
Dual Link DVI | No |
HDCP | Yes |
OpenGL version | 4.6 |
DirectX version | 12 Ultimate |
TV tuner integrated | No |
Design | |
---|---|
Product colour | Black |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 2.8 |
Form factor | Full-Height/Full-Length (FH/FL) |
Bracket height | Full-Height (FH) |
Number of fans | 3 fan(s) |
Cooling technology | Phantom Gaming 3X Cooling |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 2x 8-pin |
Minimum system power supply | 700 W |
System requirements | |
---|---|
Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
General | |
---|---|
Product Family | Phantom Gaming |
Packaging content | |
---|---|
Quick installation guide | Yes |
Weight & dimensions | |
---|---|
Depth | 305 mm |
Height | 131 mm |
Width | 56 mm |
Weight | 1.15 kg |
Packaging data | |
---|---|
Package type | Box |
ProArt GeForce RTX™ 4070 OC Edition 12GB GDDR6X brings elegant and minimalist style to empower creator PC builds with full-scale GeForce RTX™ 40 Series performance.
Compact. Creative. Power.
Blur the lines between imagination, the digital world, and reality. The ProArt GeForce RTX™ 4070 packs the venerable Ada Lovelace architecture and potent cooling into a 2.5-slot frame, bringing immense creative power to compact builds and full-scale workstations.
Empower Your Creative Flow
The Ultimate Platform for Gamers and Creators
Powered by GeForce RTX 40 Series and DLSS 3
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3 vs. brute-force rendering
Third-Gen RT Cores
Up to 2x ray tracing performance
Axial-tech Upgrades
A Fresh Spin
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
Reverse Rotation and 0dB Technology
Orchestrated Chill
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 C, referencing a speed curve that balances performance and acoustics for work or play.
2.5-slot Design
Custom Heatsink
Heatpipes efficiently wick heat into a fin stack optimized for airflow from the Axial-tech fans. The entire array is dressed in stealthy black to match the ProArt theme.
Premium Power Delivery
1st Responder
Digital power control, an array of high-current power stages, and a lineup of 15K caps ensure massive reserves to reliably push performance boundaries.
*Illustration for reference only
Compact PCB
Packs a Punch
Component and trace layouts have been optimized onto a short PCB to reduce power losses and let heat escape through a massive backplate vent.
*Illustration for reference only
Compact. Creative. Power.
The ProArt GeForce RTX 4070 is a finely-crafted synthesis of brawn and beauty.
Auto−Extreme Technology
Reliability Boost
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
Software
GPU Tweak III
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make performance tuning even easier. Additional goodies, such as, 0dB fan technology, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card. And Profile Connect allows you to seamlessly bring it all together for every creative app and task.
QuantumCloud
QuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!
Your Ideas, Accelerated by NVIDIA Studio
Creativity that’s all in. NVIDIA Studio delivers RTX and AI acceleration in top creative apps, NVIDIA Studio drivers for max stability, and a suite of exclusive tools to ignite your next big idea.
Free 3 Month of Adobe Creative Cloud
Get complimentary membership with the purchase of selected ASUS products.*
* Terms and conditions apply. For more details, please read the full terms and published on the event page.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor frequency (OC mode) | 2565 MHz |
Processor boost clock speed | 2535 MHz |
CUDA cores | 5888 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 1 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
NVIDIA G-SYNC | Yes |
Dual Link DVI | No |
HDCP | Yes |
HDCP version | 2.3 |
Virtual Reality (VR) ready | Yes |
OpenGL version | 4.6 |
Design | |
---|---|
Product colour | Multicolour |
Number of slots | 2.5 |
Number of fans | 3 fan(s) |
Cooling technology | ASUS Axial-tech |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 8-pin |
Minimum system power supply | 650 W |
Weight & dimensions | |
---|---|
Depth | 50 mm |
Height | 120 mm |
Width | 300 mm |
Weight | 992 g |
Packaging data | |
---|---|
Package type | Box |
Package weight | 1.65 kg |
Package height | 88.5 mm |
Package depth | 233 mm |
Package width | 405 mm |
ROG Strix GeForce RTX™ 4070 12GB GDDR6X OC Edition buffed-up design with chart-topping thermal performance.
with the incredible sum of its parts
The ROG Strix GeForce RTX™ 4070 brings a whole new meaning to going with the flow.
Inside and out, every element of the card gives the monstrous GPU headroom to breathe freely and achieve ultimate performance.
The unleashed reign of the NVIDIA Ada Lovelace architecture is here.
The Ultimate Platform for Gamers and Creators
Powered by GeForce RTX 40 Series and DLSS 3
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3 vs. brute-force rendering
Third-Gen RT Cores
Up to 2x ray tracing performance
Axial-tech Upgrades
A Fresh Spin
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 31% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
Reverse Rotation and 0dB Technology
Orchestrated Chill
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 C, referencing a speed curve that balances performance and acoustics for work or play.
3.12-slot Design
Through Thick and Fin
The custom sink is generously sized and structured to soak up heat from the GeForce RTX 4070 GPU so that it can be efficiently whisked away by the three Axial-tech fans.
Premium Power Delivery
1st Responder
Digital power control, an array of high-current power stages, and a lineup of 15K caps ensure massive reserves to reliably push performance boundaries.
Compact PCB
Packs a Punch
Component and trace layouts have been optimized onto a short PCB to reduce power losses and let heat escape through a massive backplate vent.
Metal Exoskeleton
Ultra-rigid
A high-quality diecast frame, shroud, and backplate tightly brace the PCB and strategically steer airflow.
Go With The Flow
It all comes together to effortlessly drive GeForce RTX 4070 performance to the max.
FanConnect II
Hook up
Two PWM FanConnect headers provide additional DIY flexibility. Chassis fans can be directly attached to the card and tuned with a curve that is based on CPU and GPU temperatures, delivering extra intake or exhaust for demanding 3D tasks.
Reinforcements
Additional Perks
A GPU bracket provides extra stability to the critical connection between die and heat spreader. The rear I/O bracket is made from stainless steel to prevent corrosion in humid climates and provide a more resilient mount. A conveniently placed Dual Bios switch allows quick selection between “performance” and “quiet” speed profiles for the Axial-tech fans.
Power Sensing
Quick Diagnosis
Know if your PSU is worthy. ROG Strix GeForce RTX 4070 graphics cards feature a high-speed circuit that constantly monitors input power from the PSU and utilizes conveniently placed LEDs to indicate voltage regulation issues and cable connection problems.
For specific instructions for connecting this graphics card to your power supply unit, please see the FAQ section.
Auto-Extreme Technology
Reliability Boost
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
Aura Sync
Symphony of Light
Aura-compatible ARGB lighting elements on the shroud and rightmost perimeter of the card provide endless possibilities for personalization with color or functional effects. Pair up with a vast range of compatible system components and coordinate the glow to create a build that’s uniquely you.
Graphics Card Holder
Pillar of Support
The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.
Software
GPU Tweak III
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
QuantumCloud
QuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!
Pair with a PSU
Check out our PSU landing page to learn more about how we’re pushing the industry forward and use our wattage calculator to estimate how much power you’ll need to fuel your next rig.
Free 1 Month of Adobe Creative Cloud
Get complimentary membership with the purchase of selected ASUS products.*
* Terms and conditions apply. For more details, please read the full terms and published on the event page.
Processor | |
---|---|
Parallel processing technology support | Not supported |
Maximum displays per videocard | 4 |
Processor frequency (OC mode) | 2640 MHz |
Processor boost clock speed | 2610 MHz |
CUDA cores | 5888 |
CUDA | Yes |
Maximum resolution | 7680 x 4320 pixels |
Graphics processor | GeForce RTX 4070 |
Graphics processor family | NVIDIA |
Memory | |
---|---|
Memory bandwidth (max) | 21 GB/s |
Memory bus | 192 bit |
Graphics card memory type | GDDR6X |
Discrete graphics card memory | 12 GB |
Ports & interfaces | |
---|---|
DisplayPort version | 1.4a |
HDMI version | 2.1 |
DisplayPorts quantity | 3 |
HDMI ports quantity | 2 |
Interface type | PCI Express 4.0 |
Performance | |
---|---|
Dual Link DVI | No |
HDCP | Yes |
HDCP version | 2.3 |
OpenGL version | 4.6 |
Design | |
---|---|
Product colour | Multicolour |
Illumination | Yes |
Illumination colour | Multi |
Number of slots | 3.12 |
Number of fans | 3 fan(s) |
Cooling technology | ASUS Axial-tech |
Cooling type | Active |
Power | |
---|---|
Supplementary power connectors | 1x 16-pin |
Minimum system power supply | 650 W |
System requirements | |
---|---|
Windows operating systems supported | Yes |
General | |
---|---|
Product Family | ROG |
Product Series | Strix |
Weight & dimensions | |
---|---|
Depth | 62.4 mm |
Height | 149.4 mm |
Width | 338.9 mm |
Weight | 1.75 kg |
Packaging data | |
---|---|
Package type | Box |
Package weight | 2.49 kg |
Package height | 88 mm |
Package depth | 227 mm |
Package width | 427 mm |
